MSI 970A-G43 AM3+ AMD 970 + SB950 6 x SATA 6Gb/s ports by AMD SB950 - Supports storage and data transfers at up to 6Gb/s USB 3.0 ATX AMD Motherboard Certified Refurbished
REFURBISHED Product Type
- AMD 970 + SB950
- FX, Phenom II X6/X4/X3/X2, Athlon II X4/X3/X2 and Sempron CPU in AM3 / AM3+ package
- DDR3 2133* (OC)/ 1866/ 1600/ 1333/ 1066
Specs
Reviews (13)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the MSI 970A-G43
| Brand | MSI |
|---|---|
| Model | 970A-G43 |
| CPU Socket Type | AM3+ |
|---|---|
| CPU Type | FX, Phenom II X6/X4/X3/X2, Athlon II X4/X3/X2 and Sempron CPU in AM3 / AM3+ package |
| FSB | HyperTransport 3.0 supporting speed up to 4.8GT/s |
| Chipset | AMD 970 + SB950 |
|---|
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 2133* (OC)/ 1866/ 1600/ 1333/ 1066 |
| Maximum Memory Supported | 32GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 2 x PCI Express 2.0 x16 slots - PCI_E2 supports up to PCIe x16 speed - PCI_E4 supports up to PCIe x4 speed |
|---|---|
| PCI Express x1 | 2 x PCI Express 2.0 x1 slots |
| PCI Slots | 2 x PCI slots, support 3.3V/ 5V PCI bus Interface. |
| Serial ATA (SATA) | 6 x SATA 6Gb/s ports by AMD SB950 - Supports storage and data transfers at up to 6Gb/s |
|---|---|
| SATA RAID | 0/1/5/10 |
| Audio Chipset | Realtek ALC887 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Realtek 8111E |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x LAN (RJ45) / 2 x PS/2 / 2 x USB 3.1 Gen 1 / 6 x Audio Jacks / 6 x USB 2.0/1.1 |
|---|---|
| PS/2 | 1 x PS/2 Keyboard 1 x PS/2 Mouse port |
| RJ45 | 1 x LAN jack |
| USB 3.0 | 2 x USB 3.0 ports (blue) |
| USB 1.1/2.0 | 6 x USB 2.0 |
| Audio Ports | 1 x 6 in 1 audio jack |
| Onboard USB | 3 x USB 2.0 connectors 1 x USB 3.0 connector |
|---|---|
| Other Connectors | 1 x ATX 24-pin power connector 1 x ATX 8-pin 12V CPU power connector CPU x 1 / System x 2 FAN connectors 1 x Front panel audio connector 1 x Front panel connector 1 x Chassis intrusion switch connector 1 x Serial connector 1 x Clear CMOS jumper 1 x TPM module connector |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.01" x 8.86" |
| Power Pin | 24 Pin |
| Features | All Solid CAP OC Genie II: Easy Overclocking Technology Support USB 3.0 and SATA 6Gb/s |
|---|
| First Listed on Newegg | July 06, 2015 |
|---|
