MSI B250M BAZOOKA LGA 1151 Intel B250 HDMI USB 3.1 Micro ATX Motherboards - Intel
REFURBISHED Product Type
- Intel B250
- Supports 6th/7th Gen Intel Core i3/i5/i7 processors, and Intel Pentium and Celeron processors for Socket LGA1151
- 7th Gen processors support DDR4 2400/ 2133*
- 6th Gen processors support DDR4 2133*
- * DDR4 memory modules can only run at maximum of 2400 MHz for 7th Gen processors and 2133 MHz for 6th Gen processors on XMP mode.
Specs
Reviews (3)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the MSI B250M BAZOOKA
| Brand | MSI |
|---|---|
| Model | B250M BAZOOKA |
| CPU Socket Type | LGA 1151 |
|---|---|
| CPU Type | Supports 6th/7th Gen Intel Core i3/i5/i7 processors, and Intel Pentium and Celeron processors for Socket LGA1151 |
| Supported CPU Technologies | * Not Compatible with Intel 8th Gen CPUs |
| Chipset | Intel B250 |
|---|
| Onboard Video Chipset | Supported only by CPU with integrated graphic |
|---|
| Number of Memory Slots | 4x288pin (DDR4) |
|---|---|
| Memory Standard | 7th Gen processors support DDR4 2400/ 2133* 6th Gen processors support DDR4 2133* * DDR4 memory modules can only run at maximum of 2400 MHz for 7th Gen processors and 2133 MHz for 6th Gen processors on XMP mode. |
| Maximum Memory Supported | 64GB |
| Channel Supported | Dual Channel |
| PCI Express 3.0 x16 | 1 x PCIe 3.0 x16 slot (supports x16 mode) |
|---|---|
| PCI Express x1 | 2 x PCIe 3.0 x1 slots |
| Serial ATA (SATA) | 6 x SATA 6Gb/s |
|---|---|
| M.2 | 1 x M.2 slot (Key M)* - Supports up to PCIe 3.0 x4 and SATA 6Gb/s - Supports 2242/2260/2280 storage devices - Intel Optane Memory Ready * The SATA1 port will be unavailable when an M.2 SATA SSD module has been installed in the M.2 slot. |
| Audio Chipset | Realtek ALC887 |
|---|---|
| Audio Channels | 7.1 Channels |
| LAN Chipset | Realtek 8111H |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x HDMI / 1 x USB 3.1 Gen 1 Type-C / 2 x PS/2 / 2 x USB 2.0/1.1 / 3 x USB 3.1 Gen 1 Type-A |
|---|---|
| PS/2 | 1 x PS/2 keyboard port 1 x PS/2 mouse port |
| Video Ports | 1 x DVI-D port |
| HDMI | 1 x HDMI |
| RJ45 | 1 x RJ45 |
| USB 3.1 | 3 x USB 3.1 Gen1 Type-A ports 1 x USB 3.1 Gen1 Type-C port |
| USB 1.1/2.0 | 2 x USB 2.0 Type-A ports |
| Audio Ports | 3 Ports |
| Onboard USB | 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) |
|---|---|
| Other Connectors | 1 x 4-pin CPU fan connector 2 x 4-pin system fan connectors 1 x Front panel audio connector 2 x Front panel connectors 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Serial port connector 1 x Parallel port connector 1 x RGB LED connecotr 1 x TBT connector 1 x Clear CMOS jumper |
| Form Factor | Micro ATX |
|---|---|
| LED Lighting | RGB |
| Dimensions (W x L) | 9.6" x 9.0" |
| Power Pin | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector |
| Features | Supports 7th / 6th Gen Intel Core / Pentium / Celeron processors for LGA 1151 socket Supports DDR4-2400 Memory (Max.) DDR4 Boost: Give your DDR4 memory a performance boost VR Ready: Best virtual reality game experience without latency GAMING LEDs: Ambient LED lights for an awesome look & feel Lightning Fast Game experience: Turbo M.2, Intel Optane Memory Ready Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience GAMING LAN: The best online gaming experience with lowest latency and bandwidth management Military Class 5, Guard-Pro: Latest evolution in high quality components for best protection and efficiency Mystic Light Sync: Synchronize other RGB solutions with your gaming rig and control all LEDs in one click In-Game Weapons: GAMING Hotkey, X-Boost EZ Debug LED: Easiest way to troubleshoot Click BIOS: Secure and Reliable UEFI BIOS solution GAMING CERTIFIED: 24-hour on- and offline game and motherboard testing by eSports players |
|---|
| First Listed on Newegg | November 17, 2017 |
|---|
