MSI MSI Gaming Z270I GAMING PRO CARBON AC LGA 1151 Intel Z270 HDMI USB 3.1 Mini ITX Intel Motherboard
- Intel Z270
- Celeron / Core i3 / Core i5 / Core i7 / Intel Core 6th Gen (LGA 1151) / Intel Core 7th Gen (LGA 1151) / Pentium
- DDR4 3200
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the MSI Z270I GAMING PRO CARBON AC
| Brand | MSI |
|---|---|
| Series | MSI Gaming |
| Model | Z270I GAMING PRO CARBON AC |
| CPU Socket Type | LGA 1151 |
|---|---|
| CPU Type | Celeron / Core i3 / Core i5 / Core i7 / Intel Core 6th Gen (LGA 1151) / Intel Core 7th Gen (LGA 1151) / Pentium |
| Chipset | Intel Z270 |
|---|
| Number of Memory Slots | 2x288pin (DDR4) |
|---|---|
| Memory Standard | DDR4 3200 |
| Maximum Memory Supported | 32GB |
| Channel Supported | Dual Channel |
| PCI Express 3.0 x16 | 1 x PCI Express 3.0 x16 |
|---|---|
| PCI Slots | 2 x PCI Slots |
| Serial ATA (SATA) | 4 x SATA 6Gb/s |
|---|---|
| M.2 | 1 x M.2 |
| SATA RAID | 0/1/5/10 |
| LAN Chipset | 1 x Intel I219-V Gigabit LAN controller |
|---|---|
| Max LAN Speed | 1Gbps |
| Wireless LAN | WiFi IEEE 802.11 a / b / g / n / ac |
| Bluetooth | Supports: Dual Mode Bluetooth 2.1, 2.1 + EDR, 3.0, 4.0, BLE, 4.2 |
| HDMI | 1 x HDMI |
|---|---|
| RJ45 | 1 x RJ45 |
| DisplayPort | 1 x DisplayPort |
| USB 3.1 | 1 x USB 3.1 Gen2 Type-A port 1 x USB 3.1 Gen2 Type-C port 2 x USB 3.1 Gen1 Type-A ports |
| USB 1.1/2.0 | 2 x USB 2.0 |
| S/PDIF Out | 1 x Optical |
| Audio Ports | 5 x OFC audio jacks |
| Antenna Connectors | 2 x antenna connectors |
| Onboard USB | 1 x USB 3.1 Gen1 connector 1 x USB 2.0 connector |
|---|---|
| Other Connectors | 1 x 8-pin ATX 12V power connector 1 x 4-pin CPU fan connector 2 x 4-pin system fan connectors(Interlinked) 1 x Front panel audio connector 2 x Front panel connectors 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper |
| Form Factor | Mini ITX |
|---|---|
| LED Lighting | RGB |
| Dimensions (W x L) | 6.7" x 6.7" |
| Power Pin | 24 Pin |
| Features | Supports 7th / 6th Gen Intel Core / Pentium / Celeron processors for LGA 1151 socket Supports DDR4-4133+(OC) Memory DDR4 Boost with Steel Armor: Give your DDR4 memory a performance boost. VR Ready: Best virtual reality game experience without latency Mystic Light and Mystic Light Sync: 16.8 milliom colors /17 effects controlled in one click with GAMING APP or mobile devices. Lightning Fast Game experience: Turbo M.2, Intel Optane Memory Ready, Lightning USB 3.1 Gen2 Audio Boost 4 with Nahimic 2: Reward your ears with studio grade sound quality for the most immersive gaming experience GAMING LAN with LAN Protect, powered by Intel : The best online gaming experience with lowest latency and bandwidth management Military Class 5, Guard-Pro: Latest evolution in high quality components for best protection and efficiency In-Game Weapons: Game Boost, GAMING Hotkey, X-Boost, Xsplit Gamecaster EZ Debug LED: Easiest way to troubleshoot Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites and search function GAMING CERTIFIED: 24-hour on- and offline game and motherboard testing by eSports players |
|---|
| First Listed on Newegg | October 18, 2017 |
|---|
