Get ready for a totally new overclocking experience that you've never had before! Based on Intel’s X58 and ICH10R chipsets, this ATX form-factor board is designed to support the latest Core i7 processors.
The DrMOS delivers a high quality power transfer to bring you a stable overlocking environment for future upgrades in processor capabilities. No application limitation of graphics cards, the MSI X58M Intel motherboard allows you to apply NVIDIA SLI and ATI CrossFire Multi-GPU technology according to your needs. Dominate your applications and games with up to 24GB of DDR3 memory fitting into six 240-pin slots with triple channel support and QPI up to 6.4GT/s for increased performance. Onboard Gigabit Ethernet LAN means that you can connect to other networked devices without running into a bottleneck.
Three PCI Express 2.0 x16 graphics cards can achieve CrossFire-linked performance at a fraction of the price. Seven 3Gb/s SATA connectors give you the ability to store massive amounts of data locally with several RAID configurations possible for extra security and high-speed performance and an eSATA port provides the same capabilities for an external drive. A half-dozen USB 2.0 ports give you additional options in connecting and expanding your system.
Get ready for a totally new overclocking experience that you've never had before! Based on Intel’s X58 and ICH10R chipsets, this ATX form-factor board is designed to support the latest Core i7 processors.
The DrMOS delivers a high quality power transfer to bring you a stable overlocking environment for future upgrades in processor capabilities. No application limitation of graphics cards, the MSI X58M Intel motherboard allows you to apply NVIDIA SLI and ATI CrossFire Multi-GPU technology according to your needs. Dominate your applications and games with up to 24GB of DDR3 memory fitting into six 240-pin slots with triple channel support and QPI up to 6.4GT/s for increased performance. Onboard Gigabit Ethernet LAN means that you can connect to other networked devices without running into a bottleneck.
Three PCI Express 2.0 x16 graphics cards can achieve CrossFire-linked performance at a fraction of the price. Seven 3Gb/s SATA connectors give you the ability to store massive amounts of data locally with several RAID configurations possible for extra security and high-speed performance and an eSATA port provides the same capabilities for an external drive. A half-dozen USB 2.0 ports give you additional options in connecting and expanding your system.
Core i7 SupportBased on the Intel X58 chipset, the MSI X58 Pro-E motherboard supports Intel’s latest generation Core i7 processors in LGA1366 socket, providing unprecedented computing power to match the performance levels you are looking for.
Scalable DDR3 MemorySix 240-pin DIMM sockets support up to 24GB of unbuffered (UDIMM) DDR3 memory at speeds of up to 1333MHz, ensuring ample capacity for any application.
NVIDIA SLI & ATI CrossFire Multi-GPU Technology SupportWith fabulous compatibility, the MSI X58M Intel motherboard supports NVIDIA SLI and ATI CrossFire Multi-GPU technologies, enabling two or more discrete graphics processors to work together for boosted system performance and breakthrough gaming experience.
Gigabit Ethernet ConnectivityThe MSI X58 Pro-E motherboard features a fast Gigabit network interface for high-speed LAN connections at up to 1000Mbps data transfer rates with advanced security features to ward off malicious attacks. Gigabit LAN is ideal for supercharged seamless streaming of Internet audio and video content.
SATA II with RAID SupportThe second generation SATA interface delivers up to 300MB/sec transfer speed, doubling that of the first generation Serial ATA. The on-board seven SATA II ports support RAID 0, 1, 5, and 10 for better performance, enhanced data security, and flexible capacity upgrades.
DrMOS TechnologyWith MSI's DrMOS Technology, the MSI X58 Pro-E motherboard features excellent energy-saving capability, offering a high-level of computing performance while maintaining an ultimate low system temperature.
Learn more about the MSI X58 Pro-E
Model
Brand
MSI
Model
X58 Pro-E
Supported CPU
CPU Socket Type
LGA 1366
CPU Type
Core i7 (LGA1366)
FSB
Supports QPI up to 6.4GT/s
Chipsets
Chipset
Intel X58
South Bridge
Intel ICH10R
Memory
Number of Memory Slots
6x240pin
Memory Standard
DDR3 800/1066/1333
Maximum Memory Supported
24GB
Channel Supported
Triple Channel
Expansion Slots
PCI Express 2.0 x16
3 x PCI Express 2.0 x16 slots (operates at 16x/16x/4x)
PCI Express x1
2 x PCI Express x1
PCI Slots
2 x PCI Slots
Storage Devices
PATA
1 x Ultra DMA 66/100/133 IDE controller, 2 Dev. Max
SATA RAID
0/1/5/10
Onboard Audio
Audio Chipset
Realtek ALC889
Audio Channels
8 Channels
Onboard LAN
LAN Chipset
Realtek 8111C
Max LAN Speed
1Gbps
Rear Panel Ports
PS/2
2
USB 1.1/2.0
6 x USB 2.0
IEEE 1394
1 x IEEE 1394a
eSATA
1 x eSATA 3Gb/s
S/PDIF Out
1 x Optical
Audio Ports
6 Ports
Internal I/O Connectors
Onboard USB
6 x USB 2.0
Onboard 1394
1 x 1394a
Physical Spec
Form Factor
ATX
Dimensions (W x L)
12.0" x 9.6"
Power Pin
24 Pin
Features
Features
Equip with 3 PCIe x16 slots, ATI CrossFire Ready and NVIDIA SLI Ready.
