Question 1

Does this come with the screw to screw it down on the stand-off?

Accepted Answer

This 100% did not come with a screw. I just got mine a week ago. I had to use a stand-off and screw set that came with my motherboard.

Question 2

anyone have advice on a heatsink for this? not finding options for a dual sided m.2

Accepted Answer

Heat sinks are not always necessary., it really depends on the environment which your PC lives and the use case of the machine. If you are doing extremely data intensive tasks, such as video editing, these drives will get hot. That said, NVME's do not like the cold, infact if they run too cool they will not run well.

Mushkins Enhanced Pilot m.2 SSDs are a little thicker( just a few microns) than other brands so it can be difficult to get a snap on cooler to fit the drive. It is possible to use the more common snap on style coolers (like Advancing Gene)  if you trim down the thermal pad thickness, however it may be best to use a cooler that is held together with a band or clip if you really need to use a cooler on this drive.

Question 3

will this work in asus prime z490-a? it's not on the manufacturer's approved list.

Accepted Answer

It really shouldn't be a problem. The PC recognize it the same any other M.2 Drive you plug in. M.2 SSD's are not like RAM where you have to have very specific model numbers to ensure compatibility, the drives use a standard protocol over the PCI bus so as along as the slot works and the drive is good, you shouldn't have anything to worry about.

Brand	Mushkin Enhanced
Series	Pilot-E
Model	MKNSSDPE2TB-D8
Device Type	Internal Solid State Drive (SSD)
Used For	Consumer

Form Factor	M.2 2280
Capacity	2TB
Memory Components	3D TLC
Interface	PCIe Gen3 x4 NVMe 1.3
Controller	Silicon Motion SM2262EN
Encryption	TCG Opal, AES, and eDrive (IEEE1667) encryption support. Self-encrypting drive (SED)

Max Sequential Read	Up to 3500 MBps
Max Sequential Write	Up to 3100 MBps
4KB Random Read	Up to 339,000 IOPS
4KB Random Write	Up to 358,000 IOPS
Seek Time	< 0.1 ms
Terabytes Written (TBW)	1300TB
MTBF	1,500,000 hours

Power Consumption (Idle)	0.3W
Power Consumption (Active)	5.7W
Operating Temperature	0°C ~ +70°C
Storage Temperature	-40°C ~ +85°C
Max Shock Resistance	1500G

Height	3.80mm
Width	22.00mm
Depth	80.00mm
Weight	7.00g

Mushkin Pilot-E 2TB PCIe Gen3 x4 NVMe 1.3 M.2 (2280) Internal SSD - Up to 3,500MBs - Opal Data Encryption - MKNSSDPE2TB-D8
