Learn more about the Netgear Inc. XSM4324CS-100NES
Model
Brand
NETGEAR
Series
ProSafe
Model
XSM4324CS-100NES
Format & Standards
Format
Stackable
Network Management Type
Managed
Ports & Interface
Primary Ports
Half-Width 24 x 10G including 24 x 10GBASE-T and 4 x SFP+ (shared)
Data Transmission
Buffer Memory
32MB
Details
Protocols
TCP/IP
PoE
No
Layer
4
Power Supply
Power
Power Consumption: 125W max
Dimensions & Weight
Dimensions
1.73" x 8.35" x 13.58"
Weight
9.12 lbs.
Environmental
Temperature
Operating temperature: 0 degree to 50 degree C (32 degree to 122 degree F) Storage temperature: –20 degree to 70 degree C (– 4 degree to 158 degree F)
Humidity
Operating Humidity: 90% maximum relative humidity, non-condensing Storage Humidity: 95% maximum relative humidity, non-condensing
Features
Features
24-port 10GBASE-T (RJ45)
4-port 10GBASE-X (SFP+) (shared, back)
480 Gbps non-blocking fabric across 24 ports
Out-of-band 1G Ethernet management port
Mini-USB and RJ45 RS232 console ports and USB storage port
Full L3 feature set and non-stop forwarding (NSF) stacking
Half-width form factor with one- and two-unit rack mount kit
Two half-width switches can be installed in a single rack space for redundant top-of-rack
Ships with one modular APS250W PSU in its power supply slot
Low acoustics (37dB @ 25 degree C / 77 degree F)
Packaging
Package Contents
Power cord (s)
RJ45 straight-through wiring serial console cable to DB9
Mini-USB console cable
Rubber caps for the SFP+ sockets
Rubber footpads for tabletop installation
Installation guide
Resource CD with the following manuals and software: Software setup manual CLI manual Software administration guide Hardware installation guide The driver for use with The Mini-USB console cable
Additional Information
Date First Available
October 17, 2016
