POE Switch ONV-POE36036PFM 24*10/100/1000M PoE RJ45 ports + 8*Gigabit SFP ports + 4*10G SFP+ ports compatible with both IEEE 802.3af/at standard.

Feature? 24*10/100/1000M PoE RJ45 ports + 8*Gigabit SFP ports + 4*10G SFP+ ports? Support L2+ Switching features, including VLAN, TRUNK, Mirroring, Port isolation/flow control/speed limit, Storm control, QOS, ACLs etc.? Support spanning tree STP, RSTP.? Jumbo frames support up to 9.6K kilobytes? Support enhanced management through WEB, CLI, TELNET, SNMP? Support cable diagnosis? 24 ports support PoE. Compatible with both IEEE 802.3 af/at. Allow PoE configuration for each PoE port Target Industries? HD monitor transmission and power supply? Wireless AP layout transmission and power supply? Network telephone transmission, intelligent house and home system? Intelligent transportation supervisory system (ITS)? High-speed Way supervisory/Tele-Communication System? Security protection system, TV medical treatment? Long-distance Muti-media Schooling, Campus monitoring? Long-distance broadcast television transmission system? High-building Security Protection, Military Tele-Com projects Ordering Information
Product Model: ONV-POE36036PFM
Product Description: 36-port 10G L2+ Managed Core PoE Switch, 24*10/100/1000M PoE RJ45 ports + 8*Gigabit SFP ports + 4*10G SFP+ ports, compatible with both IEEE 802.3 af/at standard.
Max PoE port power: 30W, can be set by management system. Total input power is 400W.
Note: Default power supply pin type is end-span(1/2+, 3/6-) Technical parameter list Product Name 36-port 10G Managed L2+ Core PoE Switch Model ONV-POE36036PFM Connector Type 24*10/100/1000M PoE RJ45 ports + 8*Gigabit SFP ports + 4*10G SFP+ ports
Network Media 10BASE-T: UTP Cat 3, 4, 5 (=100
Meters) 100BASE-TX: UTP Cat 5 or more (=100
Meters) 1000BASE-T: UTP Cat 5 or more (=100 Meters) Bandwidth 598G Address Database Size 32K MTBF 100, 000 hours Forwarding Mode Store and Forward Buffer Memory 32M Network Protocols IEEE 802.3, 10BASE-T Ethernet; IEEE 802.3 u, fast Ethernet Standard; IEEE 802.3 ab, gigabit Ethernet Standard; IEEE 802.3 z, gigabit Ethernet Fiber Standard; (AOC fiber cable) IEEE 802.3 ae, 10G Ethernet Standard; IEEE 802.3 x, full-duplex Ethernet data link layer flow control; PoE Ports 24*PoE Ports PoE Port Power Max 30W PoE Standard IEEE 802.3 af/at Working Environment -40~+80°C Certification CE, FCC, RoHS Transmission Distance 100 meters for RJ45 port Power Supply Type end-span(1/2+, 3/6-) QoS Yes VLAN Yes Product Size 440*290* 44.5 mm Warranty 1 year
