Unifi Ubiquiti Networks U7 Industrial (U7-Industrial)

IP67 industrial WiFi 7 access point with extended-temperature operation, integrated high-gain directional RF system with adjustable isolation and beamwidth control.

OverviewDimensions:Device: 170 x 103 x 41.2 mm (6.7 x 4.1 x 1.6")Ball mount installed: 170 x 103 x 107.6 mm (6.7 x 4.1 x 4.2")Adjustable reflectors installed: 177.6 x 299.7 x 177.8 mm (7 x 11.8 x 7")Omnidirectional antennas installed: 341.8 x 103 x 107.6 mm (13.5 x 4.1 x 4.2")WiFi Standard: WiFi 7Spatial Streams: 4Coverage Area: 465 m² (5,000 ft²)Max. Client Count: 200+Uplink: 2.5 GbEMounting: Wall, Pole (Mounts included)Weatherproofing: IP67Power Method: PoEPerformanceMIMO:5 GHz: 2 x 2 (DL/UL MU-MIMO)2.4 GHz: 2 x 2 (DL/UL MU-MIMO)Max. Data Rate:5 GHz: 4.3 Gbps (BW240)2.4 GHz: 688 Mbps (BW40)Antenna Gain:5 GHz:Directional Internal (Built-in): 10 dBi, 95° x 45°Directional Internal (Reflector Wide Angle): 11 dBi, 70° x 45°Directional Internal (Reflector Narrow Angle): 12 dBi, 55° x 45°External omni: 6 dBi, 360° x 45°2.4 GHz:Directional Internal (Built-in): 8 dBi, 100° x 45°Directional Internal (Reflector Wide Angle): 9 dBi, 80° x 45°Directional Internal (Reflector Narrow Angle): 10 dBi, 65° x 45°External omni: 5 dBi, 360° x 45°Max. TX Power:5 GHz: 24 dBm2.4 GHz: 23 dBmFeaturesWireless Meshing: Band Steering: 802.11v BSS Transition Management: 802.11r Fast Roaming: 802.11k Radio Resource Management (RRM): Advanced Radio Management: Real Time Spectral Analysis: Passpoint (Hotspot 2.0): Captive Hotspot Portal: Custom Branding Landing Page: Voucher Authentication: Payment Based Authentication: External Portal Server Support: Password Authentication: Guest Network Isolation: Private Pre-Shared Key (PPSK): WiFi Speed Limiting: Client Device Isolation: WiFi Schedules: RADIUS over TLS (RadSec): Dynamic RADIUS assigned VLAN: HardwareMax. Power Consumption: 13WSupported Voltage Range: 42.557V DCNetworking Interface: (1) 2.5 GbE RJ45 portWeight:Device: 577 g (1.3 lb)Ball mount: 163 g (5.8 oz)Reflector antenna set: 500 g (1.1 lb)Omni antenna set: 52 g (1.8 oz)Wind Loading: 97.3 N at 200 km/h (21.9 lbf at 125 mph)Pole Mount Diameter: 12.5" (2563.5 mm)Management: EthernetEnclosure Material: UV stabilized polycarbonate, aluminum alloyMount Material: Aluminum alloyLEDs:System: (4) Blue: signal / (1) White/Blue: IndicatorAmbient Operating Temperature: -40 to 70° C (-40 to 158° F)Ambient Operating Humidity: 5 to 95% noncondensingNDAA Compliant: Certifications: CE, FCC, IC
