Ubiquiti Networks Wireless AP

• WiFi Generation: Wi-Fi 7
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6/6E) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) 802.11be (WiFi 7) 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
• Interface: (1) 1/2.5 GbE RJ45 port
• Brand: Ubiquiti Networks
• Model #: U7-Pro

• WiFi Generation: Wi-Fi 7
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6/6E) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) 802.11be (WiFi 7) 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
• Interface: (1) 1/2.5 GbE RJ45 port
• Brand: Ubiquiti Networks
• Model #: U7-Pro-Wall

• WiFi Generation: Wi-Fi 5
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac 6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
• Interface: (1) GbE RJ45 port
• Brand: Ubiquiti Networks
• Model #: UAP-AC-M-US

• Frequency Band: 5.0 GHz
• WAN Ports: 1 x 10/100 Ethernet Port
• Interface: RJ-45
• Brand: Ubiquiti Networks
• Model #: LOCOM5(US)

• Series: WIFI Extender
• Standards: 802.11a/b/g/n/ac/ax (WiFi 6)
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 600 Mbps (MCS0 - MCS31 , HT 20/40) 802.11ac 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) 802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
• Antenna: 2.4 GHz 2 x 2 (DL/UL MU-MIMO) 5 GHz 4 x 4 (DL/UL MU-MIMO)
• Model #: U6-Extender-US

• Frequency Band: Max. TX power* 29 dBm *Depends on regional regulations. Frequency accuracy ± 2.5 ppm without GPS Synchronization ± 0.2 ppm with GPS Synchronization Channel bandwidth 10/20/30/40/50/60/80/100 MHz selectable Programmable Uplink and Downlink duty cycles Operating Frequency (MHz) Worldwide 4800 - 6200 MHz* *Depends on regional regulations. US/ CA U-NII-1 U-NII-2A U-NII-2C U-NII-3 5150 - 5250 MHz 5250 - 5350 MHz 5470 - 5725 MHz 5725 - 5850 MHz
• LEDs: N/A
• Power Supply: Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) Passive PoE 2-pairs (4, 5+; 7, 8-) or (1, 2+; 3, 6-) Power supply 24V, 1A gigabit PoE adapter (Included) Supported voltage range 18—54V DC Max. power consumption 12W
• Temperature: -40 to 55° C (-40 to 131° F)
• Model #: AF-5XHD-US

• WiFi Generation: Wi-Fi 6
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
• Interface: (1) GbE RJ45 port
• Brand: Ubiquiti Networks
• Model #: U6-PLUS

• WiFi Generation: Wi-Fi 6
• Wireless Data Rates: 802.11ac 6.5 Mbps to 1300 Mbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80) 802.11n 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40) 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps
• Interface: 2 x 10/100/1000 Ethernet Ports
• Brand: Ubiquiti Networks
• Model #: UAP-AC-PRO-5-US

• WiFi Generation: Wi-Fi 6
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40) 802.11ac 6.5 Mbps to 1.3 Gbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80)
• Interface: (2) GbE RJ45 ports
• Brand: Ubiquiti Networks
• Model #: U6-MESH-PRO-US

• Wireless Data Rates: Max Data Rates: 5 GHz: 867 Mbps (BW80)
• Frequency Band: US/CA: U-NII-1 5150 - 5250 MHz U-NII-2A 5250 - 5350 MHz U-NII-2C 5470 - 5725 MHz U-NII-3 5725 - 5850 MHz
• Interface: (2) GbE RJ45 ports
• Brand: Ubiquiti Networks
• Model #: UDB-PRO

• WiFi Generation: Wi-Fi 6E
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 600 Mbps (MCS0 - MCS31 , HT 20/40) 802.11ac 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) 802.11ax (WiFi 6/6E) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
• Interface: (1) Data in: 1/2.5 GbE RJ45 port (4) Data out: GbE RJ45 ports
• Brand: Ubiquiti Networks
• Model #: U6ENTERPRISEIWC

• WiFi Generation: Wi-Fi 5
• Interface: 4 x Gigabit Ethernet Ports
• Brand: Ubiquiti Networks
• Part Number: ACB-AC-US
• Model #: ACB-AC-US

• WiFi Generation: Wi-Fi 7
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) 802.11be (WiFi 7) 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
• Interface: (1) 1/2.5 GbE RJ45 port
• Brand: Ubiquiti Networks
• Model #: U7-Outdoor

+ $26.91 off w/ promo code MMSF832, limited offer

• Frequency Band: Operating Frequency (MHz) Worldwide 5150-5875 MHz USA U-NII-1 U-NII-2A U-NII-2C U-NII-3 5150-5250 MHz 5250-5350 MHz 5240-5725 MHz 5725-5850 MHz Management Radio (MHz) Worldwide 2412 - 2472 MHz US/CA 2412 - 2462 MHz
• Power Supply: Power method Passive PoE 2-pair (4, 5+; 7, 8 return) Max. power consumption 8.5W Supported voltage range 20—27V DC Power supply 24V, 0.5A gigabit PoE adapter (Included) ESD/EMP protection Air/contact: ± 24 kV
• Temperature: -40 to 70 C (-40 to 158 F)
• Humidity: 5 to 95% noncondensing
• Model #: PBE-5AC-Gen2

• WiFi Generation: Wi-Fi 6
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) 802.11ac 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) 802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
• Interface: (1) GbE RJ45 port
• Brand: Ubiquiti Networks
• Model #: U6-Mesh

• WiFi Generation: Wi-Fi 6
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) 802.11ac 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) 802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
• Interface: (1) Data-in: GbE RJ45 port (4) Data-out: GbE RJ45 ports
• Brand: Ubiquiti Networks
• Model #: U6-IW-US

• Model #: CKG2-RM

• Model #: UCG-Fiber

• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 600 Mbps (MCS0 - MCS23, HT 20/40) 802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80)
• Interface: (1) GbE RJ45 port (1) 1/10 GbE ICM Ethernet port
• Standards: 802.11 a/b/g/n/ac
• Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11w/PMF
• Model #: UWB-XG-US

• WiFi Generation: Wi-Fi 7
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6/6E) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) 802.11be (WiFi 7) 5 GHz 6 GHz 7.3 Mbps to 8.6 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240) 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
• Interface: (1) 1/2.5 GbE RJ45 port
• Brand: Ubiquiti Networks
• Model #: U7-Pro-Max

• WiFi Generation: Wi-Fi 7
• Brand: Ubiquiti Networks
• Series: Outdoor AP
• Part Number: U7-Pro-Outdoor-US
• Model #: U7-Pro-Outdoor-US

• WiFi Generation: Wi-Fi 5
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40) 802.11ac 6.5 Mbps to 1.3 Gbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80)
• Interface: (2) GbE RJ45 ports
• Brand: Ubiquiti Networks
• Model #: UAP-AC-PRO-US

• WiFi Generation: Wi-Fi 5
• Wireless Data Rates: Max. Data Rate: 5 GHz: 866.7 Mbps (BW80) 2.4 GHz: 300 Mbps (BW40) Supported Data Rates 802.11ac (WiFi 5): 6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80) 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
• Frequency Band: Operating Frequency US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5725 MHz
• Interface: RJ-45
• Model #: UK-ULTRA-US

• Wireless Data Rates: 1.0+ Gbps Maximum Throughput
• WAN Ports: (1) 10/100 Ethernet Port (Configuration Port) (1) RJ-12, Alignment Tone Port
• Interface: (1) 10/100/1000 Ethernet Port
• Brand: Ubiquiti Networks
• Model #: AF-5

• WiFi Generation: Wi-Fi 6
• Brand: Ubiquiti Networks
• Part Number: Wave-Pro-US
• Standards: IEEE 802.11ax
• Model #: Wave-Pro-US

• Frequency Band: 5.1-5.8 GHz
• Brand: Ubiquiti Networks
• Series: Rocket Dish
• Dimensions: 16.57" x 41.34" x 41.34"
• Model #: RD-5G-34

• Frequency Band: RF Operating frequency* 57–71 Ghz * Depends on regulatory region. Channel bandwidth 2160, 1080 MHz Polarization Vertically linear Beamwidth Azimuth: 3 dB 1.6° Elevation: 3 dB 1.6°
• LEDs: Power Flashing white: bootup in progress White: not connected to UISP application Blue: connected to UISP application Ethernet Flashing blue: Ethernet activity GPS Blue: receiving at least (4) GPS satellite signals 60G Blue: active connection
• Power Supply: Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only Power supply 48V DC, 0.65A gigabit PoE adapter (Included) Supported voltage range 44–54V DC 22–27V DC
• Temperature: -40 to 60° C (-40 to 140° F)
• Model #: AF60-LR

• Model #: U7-Pro-XG-B

• WiFi Generation: Wi-Fi 7
• Wireless Data Rates: Max. Data Rate 6 GHz: 5.8 Gbps (BW320) 5 GHz: 4.3 Gbps (BW240) 2.4 GHz: 688 Mbps (BW40) Supported Data Rates 802.11be (WiFi 7): - 6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320) - 5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240) 802.11ax (WiFi 6): - 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) - 802.11ac (WiFi 5): - 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11n: - 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
• Interface: (1) 10 GbE RJ45 port
• Brand: Ubiquiti Networks
• Model #: U7-Pro-XG-Wall

• WiFi Generation: Wi-Fi 6
• Wireless Data Rates: 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) 802.11ac 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) 802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
• Frequency Band: 5 GHz
• Interface: (1) GbE RJ45 port
• Model #: U6-PRO

• Interface: (1) GbE RJ45 port
• Brand: Ubiquiti Networks
• Part Number: Loco5AC-5
• Power Supply: 24V, 0.3A gigabit PoE supply (Not included)
• Model #: Loco5AC5US

• WiFi Generation: Wi-Fi 5
• Interface: 2 x 10/100/1000 Ethernet Ports
• Brand: Ubiquiti Networks
• Part Number: UAP-AC-HD-US
• Model #: UAP-AC-HD-US

• WiFi Generation: Wi-Fi 5
• Interface: 1 x 10/100/1000 Ethernet Port
• Brand: Ubiquiti Networks
• Part Number: UAP-NANOHD-US
• Model #: UAP-NANOHD-US
