2021 Upgraded version GPD Win Max Mini Handheld Windows 10 Video Game Console Gameplayer 8 Inch Laptop Notebook UMPC Tablet PC CPU Intel i7-1195G7 16GB RAM + 1T NVMe SSD

The ultra-durable dual 3D joysticks produced by Japan Alps, can be used as L3 / R3 buttons (support 360 ° rotation) after pressing down,the potentiometer and center stack of the joystick can be used for 2 million and 5 million spins respectively.

The ABXY buttons are still made with double layer silk-printing, with appropriate spacing between the buttons that facilitates comfortable pressing without errors.

The L1 / L2 R1 / R2 buttons all have highly-reliable Panasonic micro switches, with mechanical service life reaching 10 million times and electrical service life reaching 100,000 times, and operating temperature of -54 ~ 177 degrees Celsius.

High Displacement Side-blow Design, 9 Ventilation Holes For Fast Heat Dissipation


CPU


Product model: Core™ i7-1195G7

# of Cores / # of Threads: 4/8

Processor Base Frequency:2.90 GHz

Turbo (1 Core):5.00 GHz

Turbo (All Core):4.60 GHz

Level 2:5 MB

Level 3:12 MB

Core Architecture:Tiger Lake UP3

Lithography::10nm

TDP:15W,20W,25W
Under single-core performance test, i7-1195G7 / i7-1165G7 performs outstandingly, surpassing the desktop flagship i9-10900K.


For A Productivity Tool, The Higher The Score Of Multi-core Performance, The Better
About Core Display Comparison, The Intel Iris Xe Core Display Has Obvious Advantages, The Overall Performance Exceeds MX350

GPU


Graphics Card:Integrated Graphics

Processor Graphics:Intel Iris Xe Graphics 96

Graphics Base Frequency:400 MHz

Graphics Max Dynamic Frequency:1.40 GHz

Execution units:96 EUs

Shaders:768

Video Memory:Shared Memory

4K Image resolution:Yes

DirectX:12

OpenGL:4.6

Storage


Memory:16GB

Memory Types:LPDDR4x-4266

Memory Dual Channel:Yes

Hard Disk Type:M.2 SSD

Hard Disk Interface:Socket 3

Hard Disk Specifications:PCIe 3.0/4.0 M.2 NVMe 2280

Standard Capacity:1TB, Replaceable, No Capacity Limit

Bus Specification:PCIe Gen 3.0 / 4.0 × 4

Transfer Protocol:NVMe 1.3 / 1.4


I/O Interface


Data / Charging / Video Interface:2×USB4,1×HDMI 2.0b,2×USB 3.2 Gen 1 Type-A

microSDXC Slot:Support

Keyboard:Chiclet Keyboard, Backlight design

TouchPad:Support Lnput, With Press Down Button

I/O Device


Mouse:Analog Simulated Mouse, Need To Switch "GamePad / Mouse" Mode

Joystick:Originally Provided by Japan ALPS, Double 3D Joystick (Compatible With PSV Joystick), Press Supports L3 / R3

D-Pad:Integrated style

Game Function Buttons:ABXY???×? Double Character Print, Select, Start, Xbox
Controller Home

Game Accessories Buttons:L1/L2/R1/R2, Panasonic Microswitch

Indicator Lamp:Mute Indicator, Charging Indicator, Operation indicator

Reset:Support

Battery


Battery Type:Li-polymer

Battery Capacity:57Wh, 11.4V==5000mAh×3 Series

Battery Life:3 Hours Of Heavy Use, 6-8 Hours Of Moderate Use, 14 Hours Of Light Use, Depending On The Specific Environment Of Use


Appearance


Net Weight:790g

Length:207×145×26 mm

Shell Material:LG-DOW 121H Aviation ABS, UL94-V0, Magnesium alloy

Shell Color:Black

Thermal Design:Active Cooling Method, Dual Fan, Dual Heat Pipe

Sensor:Hall Sensor


Accessories


Package Specifications

GPD WIN Max 2021× 1

Power Adapter(20V==3.25A) ×1

Warranty Card ×1

Specification ×1
