Panasonic REQ12 Series 8000-Lum Pixel Shift UHD 4K DLP Projector PT-REQ80WU

Product Information

• Part Number: PT-REQ80WU
• Manufacturer: Panasonic
• Product Name: Panasonic REQ12 Series 8000-Lum Pixel Shift UHD 4K DLP Projector PT-REQ80WU
• Color: White
• TAA Compliant: True
• SKU: PT-REQ80WU

Product Description

The Panasonic PT-REQ80WU is a next-generation 1-Chip DLP 4K Laser Projector designed for demanding commercial applications like museums and entertainment venues. It delivers exceptional, highly engaging immersive experiences with up to 8000 ISO lumens brightness, UHD 4K (3840 x 2400) on-screen resolution via Panasonic's Quad Pixel Drive technology, and 240 Hz projection capability. The projector features an hermetically sealed optical block with all-liquid cooling, enabling 20,000 hours of maintenance-free projection. It supports 4K HDR and HDCP 2.3 via HDMI and DisplayPort inputs. The PT-REQ80WU offers effortless workflow and improved expandability with a new line of compatible lenses, an Intel SDM-specified slot for integrating function boards, NFC function for network prep, and pre-activated upgrade kits for Geo Pro software.

Product Specifications

• Display System: 1-Chip 0.80" DLP
• Native Resolution: 1920 x 1200
• On-Screen Resolution: Up to 3840 x 2160 (via Pixel-Shift Technology)
• Maximum Brightness: 8000 Lumens (ISO)
• Light Source: Laser Phosphor
• Expected Lamp Life: 20,000 Hours (Medium Brightness), 24,000 Hours (Low Brightness)
• Dynamic Contrast Ratio: 25,000:1 (Full On/Full Off, Dynamic Contrast [3])
• Aspect Ratio: Native: 16:10, Supported: 16:9
• Throw Ratio: 1.36 to 2.10:1 (with supplied lens)
• Projection Size: 70 to 700 inches (diagonal)
• Lens Included: Yes (Powered zoom/focus lens, f/1.84 to 2.31, Focal Length: 23.9 to 37.2mm)
• Lens Shift: Vertical: ±60% (powered), Horizontal: ±29% (powered)
• Optical Zoom: Powered
• HDR Support: Yes (HDR10/Hybrid Log Gamma)
• Inputs/Outputs: {'HDMI': '2x HDMI Audio, Video Input (Deep Color, HDCP 2.3, 4K/60p signal input)', 'DisplayPort': '1x DisplayPort Audio, Video Input (Deep Color, HDCP 2.3, 4K/60p signal input)', 'USB-A': '1x USB-A Data, LAN Input, 1x USB-A Power Output (DC 5V, 2A)', 'RJ45 (Ethernet)': '1x RJ45 (Ethernet) Control, Data, LAN Input/Output (PJLink Class 2, Art-Net compatible)', 'DE-9/DB-9 (RS-232)': '1x Control Input (RS-232C compliant), 1x Control Output (RS-232C compliant)', 'BNC': '1x Multi Sync Input, 1x Multi Sync Output', 'Mini Remote': '1x 1/8" (3.5 mm) Input, 1x 1/8" (3.5 mm) Output', 'Expansion Slots': '1 (Intel® SDM compatible)'}
• Power Supply: AC 100-240 V, 50/60 Hz
• Power Consumption: Full Brightness: < 760 W (AC 100-120V), 730 W (AC 200-240V)
• Operating Conditions: 32 to 113°F / 0 to 45°C at 10 to 80% Humidity
• Fan Noise: 35 dB (NORMAL/ECO), 32 dB (QUIET)
• Dimensions (W x H x D): 498 x 212 x 648 mm (19.6 x 8.3 x 25.5 inches) (with Lens and Feet)
• Weight: 28.8 kg (63.5 lbs) (with supplied lens)
• Security: Cable Lock Slot, Password Protection
• Installation: Ceiling/floor, front/rear, free 360-degree installation
