4K@60Hz HDMI to HDMI Video Converter Image Rotator 90/180/270 Degree,Support Up and Down Frequency Conversion,Frame Rate Changes,Audio Synthesis and Separation

Introduction: This is a high-performance support for 4K@60Hz input and output of the audio and video converter products. Support up and down frequency conversion, frame rate change, support audio synthesis and separation; new graphics algorithm, high definition, high turn low, low turn high font are very clear, completely no fork. Can rotate the picture and other operations, simple and easy to use. Feature Compliance with HDMI 2.0 b and HDCP 2.2 / 1. x specifications Supports 18Gbps video bandwidth Input and output video resolution up to 4K@60Hz Support 3.5 mm audio embedding and 3.5 mm audio decoding output
HDMI input: 720*480~4096 * 2160/60Hz and unconventional resolution input
HDMI output: 4Kx2K 60hz/30hz/25hz, 3840x1080 60hz, 3440x1440 60hz, 2560x1600 60hz/120hz/144hz, 1920x1200 60hz, 1080P 60hz/50hz/30hz, 1600x1200 60hz, 720 60hz etc. Compatible DVI Without software settings, support for hot plug, Plug and play function Image rotation 90°, 180°, 270° Using DC12V / 1A external power adapter power supply, Install a simple Can be customized according to the user needs
Parameters: HDMI
compatible: HDMI 2.0 b
HDCP compatible: HDCP 2.2 / 1.
x Video bandwidth: 18 Gbps
Input resolution: up to 4K@60Hz
Output resolution: up to 4K@60Hz, Menu selection
Color space: RGB, YCbCr
4:4: 4, YCbCr
4:2: 2, YCbCr
4:2: 0
Audio Format: HDMI
Audio: PCM 2.0 / 5.1 / 7.1CH, Dolby Digital/Plus, DTS, DTS High Res
Analog audio: PCM 2.0
Input port: 1 x HDMI IN [Type A, 19-pin port] 1 x L/R OUTPUT [RCA]
Output port: 1 x HDMI OUT
