New Kenwood KAC-7005PS 1200W 5 Channel Car Amplifier
- New Kenwood KAC 7005PS 1200W 5 Channel Car Amplifier
- RMS Power Rating:
- 40 Watt x 4 Channel + 300 Watt x 1 Channel @ 4 Ohm
- 50 Watt x 4 Channel + 50 Watt x 1 Channel @ 2 Ohm
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
5-Channel Performance Series Car Amplifier 40 watts RMS x 4 at 4 ohms + 300 watts x 1 at 4 ohms 50 watts RMS x 4 at 2 ohms + 500 watts RMS x 1 at 2 ohms 100 watts RMS x 2 bridged at 4 ohms + 500 watts RMS x 1 at 2 ohms Pulse Width Modulated MOSFET power supply LED power (green) and protect (red) indicators Variable Bass Boost (0 to +18 dB bass boost at 50 Hz) Soft start turn-on 5/4/3/2 or Mono channel operation Preamp RCA outputs to daisy chain multiple amps 3-way protection circuitry (thermal, overload, and speaker short protection) Nickel-plated RCA level inputs Nickel-plated screw terminals Variable high-pass filter (50-200 Hz, 24 dB/octave) Variable low-pass filter (50-200 Hz, 24 dB/octave) Frequency response: 5-50000 Hz
Kenwood 5 Channel Amplifier 700 Watts - KAC-7005PS
- 5-Ch Design - Power your entire system with a single 5-channel amplifier. This powerful one amplifier solution for front and rear speakers plus subwoofers, is an easy solution for any vehicle to enhance your factory sound system.
- Variable High-Pass Filter - Filters low frequencies out of the music and passes only signals above a certain frequency (called the cut-off frequency) to mid and high range speakers.
- Variable Low-Pass Filter - Filters high frequencies out of the music and improves efficiency and sound quality by allowing only the low frequencies to pass to the subwoofer.
- Variable Bass Boost - Adjust the fixed bass boost frequency (40Hz) to maximize natural bass performance.
| General Features | |
|---|---|
| Operating Voltage | 14.4V (11 - 16 V allowable) |
| Current Consumption | 54 A |
| Dimensions (W x H x D) | 324 x 55 x 187 mm (12-3/4 x 2-3/16 x 7-3/8) |
| Weight | 2.8 kg (6.1 lbs) |
| Warranty | - |
Specifications
| CEA-2006 Standard | 40 W x 4 | RMS Watts per channel @ 4 ohms, 1% THD+N |
| 300 W x 1 | RMS Watts per channel @ 4 ohms, 1% THD+N | |
| 80dBA | Signal to Noise Ratio (Reference: 1 Watt into 4 ohms) | |
| Max Power Output | 1200 W | |
| Rated Power Output | 14.4 V 40 W x 4 / 300W x 1 | (4?) (20 Hz - 20 kHz, 1.0% THD) (20 Hz - 200 Hz, 1.0% THD) |
| 50 W x 4 / 500W x 1 | (2?) (1 kHz, 1.0% THD) (100 Hz, 1.0% THD) | |
| 100 W x 2/ 300W x 1 | Bridged (4?) (1 kHz, 1.0% THD) (20 Hz - 200 Hz, 1.0% THD) | |
| Frequency Response | 20-20kHz(±1dB) | |
| Input Sensitivity | 0.2 V - 5.0 V (MIN-MAX) | |
| Input Impedance | 10 k? | |
| Signal to Noise Ratio | 100 dB | |
| Low Pass Filter Frequency | (-24 dB/oct.) 50 Hz - 200 Hz (variable) | Low-Pass Filter Frequency |
| High Pass Filter Frequency | (-12 dB/oct.) 50 Hz - 200 Hz (variable) | High-Pass Frequency |
| Dimensions (W x H x D) | 324 x 55 x 187 mm (12-3/4 x 2-3/16 x 7-3/8) | |
