    Turntable High Performance Phono Cartridge & Stylus

    Be the first to review this product...
    • Frequency Response: 20ï½?20000Hz
    • Output voltage: 3.5mV (1kHz 5cm/sec.)
    • Channel separation: 20dB (1kHz)
    • Output balance: 2.0dB (1kHz)
    • Needle pressure: 1.5-2.5g (recommended gauge pressure 2.0g)
    • Coil impedance: 2.8kΩ (1kHz)
    • Coil DC resistance: 410Ω
    • Recommended load resistance: 47kΩ
    • Load capacitance: 100ï½?200pF
    • Coil inductance: 400mH (1kHz)
    • Static obedience: 20Ã?10-6cm/dyne
    • Dynamic compliance: 6.5Ã?10-6cm/dyne(100Hz)
    • Tip shape: elliptical needle (0.4Ã?0.7mil)
    • Needle bar: aluminum alloy tube
    • Vertical tracking angle: 20°
    • Dimensions: H17.2Ã?W17.0Ã?D30.5mm
    • Cartridge weight: 5.7g ...
    +
    +
    Overview
    Specs
    Reviews
    avatar

    Any questions? Our AI beta will help you find out quickly.

    Try me now

    Improve your turntable's sound and fidelity with this high-performance cartridge and stylus.  Precision e

    lliptical diamond stylus with dual magnet cartridge pick-ups.  Manufactured with advance carbon fiber materials for the lightness and even-weight distribution. Includes head shell mounting screws.

    SPECIFICATIONS:

    • Frequency Response: 20~20000Hz

    • Output voltage: 3.5mV (1kHz 5cm/sec.)

    • Channel separation: 20dB (1kHz)

    • Output balance: 2.0dB (1kHz)

    • Needle pressure: 1.5-2.5g (recommended gauge pressure 2.0g)

    • Coil impedance: 2.8kO (1kHz)

    • Coil DC resistance: 410O

    • Recommended load resistance: 47kO

    • Load capacitance: 100~200pF

    • Coil inductance: 400mH (1kHz)

    • Static obedience: 20×10-6cm/dyne

    • Dynamic compliance: 6.5×10-6cm/dyne(100Hz)

    • Tip shape: elliptical needle (0.4×0.7mil)

    • Needle bar: aluminum alloy tube

    • Vertical tracking angle: 20°

    • Dimensions: H17.2×W17.0×D30.5mm

    • Cartridge weight: 5.7g
