Serial Bus Servo Driver Board with Servo Power Supply and Control Circuit, Suitable for ST/SC Series Serial Bus Servos, Supports Controlling up to 253 ST/SC Series Serial Bus Servos at the Same Time
- UART serial bus control: Allows controlling up to 253 SC/ST series serial bus servos at the same time, supports receiving the operating status and various information feedback of each servo
- Compatible Servos: Supports ST/SC series bus servos, and can directly power the servos via DC power jack, supports selecting power supply input according to the servo used
- Supports UART and USB control: Switching the control mode by selecting A or B via the jumper. Two Power supply methods: Onboard DC5521 power jack and screw terminal for easy integration into existing projects
- Easy to use with USB control: Connect the driver board to the host via a USB cable to easily control the serial bus servo and receive data feedback, speeding up the project prototyping process
- Application: Servos will provide various feedback like position, speed, torque lock, and operating mode (servo mode, servo motor mode, etc.) for advanced projects requiring closed-loop automatic control. Ideal choice for building qu
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Serial Bus Servo Driver Board, Integrates Servo Power Supply And Control Circuit, Applicable for ST/SC Series Serial Bus Servos, Small In Size, Easy to Integrate Features Supports connecting to a host or MCU to control the serial bus servos Allows controlling up to 253 ST/SC series serial bus servos at the same time (sufficient power supply required) 9~ 12.6V voltage input (the input voltage and the servo voltage must be matched) Provides convenient serial bus servo control solutions Integrates control circuit to ensure the stable operation of serial bus servo Compact size and space saving, suitable for integration into sorts of space-limited projects
) for advanced projects requiring closed-loop automatic control Ideal choice for building quadruped robots, hexapod walkers, robotic arms and other robotic projects requiring multiple servos Compact size, suitable for integration into sorts of space-limited projects How-to-use document/User
Manual: //bit. ly/45pNP44 Package Content Bus Servo Adapter (A) x1
Specifications
Power Supply ---DC 9~ 12.6V (ST series servo) Power supply connector --- 5.5 × 2.1 mm DC communication interface---UART Dimensions--- 42.00 × 33.00 mm Mounting hole size--- 2.50 mm Mounting hole spacing--- 37.00 × 28.00 mm Application examples Servos will provide various feedback like position, speed, torque lock, and operating mode (servo mode, servo motor mode, etc.) for advanced projects requiring closed-loop automatic control Ideal choice for building quadruped robots, hexapod walkers, robotic arms and other robotic projects requiring multiple servos Compact size, suitable for integration into sorts of space-limited projects How-to-use document/User
Manual: //bit. ly/45pNP44 Package Content Bus Servo Adapter (A) x1
