Specifications:
Brand: YONGNUO
Model:
YN560LiInput: AC100-240V, 50/60Hz, 0.3A;
Output: 5V, 2ACircuit
Design: Insulated Gate Bipolar Transistor (IGBT)
Guide No.: 58 (ISO 100, 105mm)Flash
Mode: M, Multi
Trigger Mode: On-camera, TX, RX, S1, S2Zoom
Range: 24, 28, 35, 50, 70, 80, 105mm
Vertical
Rotation Angle: -7~90 degrees
Horizontal Rotation Angle: 0~270 degrees
Power Supply: 2 pieces of 18650 lithium-ion battery
Number of
Flashes: 500 times (using 18650 lithium-ion battery)Recycling
Time: Less than 2s (using 18650 lithium-ion battery)Color
Temperature: Approx.
5600KFlash Time: 1/200s~1/20000sFlash
Control: 8 levels of output control (1/128~1/1), 29 levels of fine tuning totally
External Interface: Hot shoe, PC port, Micro USB port
Wireless Triggering Distance: Photosensitive triggering distance for indoors, 20-25m, 10-15m for outdoors. 2.4G radio triggering distance, up to 100mItem
Size: Approx. 58 * 76 * 191mm (Extended state)
Item Weight: 393g / 13.9 ozPackage
Size: 23.2 * 17.4 * 9.8 cm / 9.1 * 6.9 * 3.9 inPackage
Weight: 968g / 34.2 oz
Features: Portable Lithium
Battery Power Supply: This speedlite works normally with just 2pcs of 18650 batteries. The number of full power flash is up to 500 times. Compatible with YONGNUO 602/603
Wireless Triggering System: This speedlite is completely compatible with YONGNUO YN720/YN685/YN560 IV/YN660/YN560 III/YN560 TX/RF605/RF603/RF602 wireless triggering signal. There are 16 channels for selection and the effective triggering distance is up to 100m. Wireless Transceiver Module, Control Flash Parameters of 6
Groups: One same YN560Li speedlite can be used as master flash or slave flash. When it's used as master flash, it supports controlling 6 individual groups, and it can remotely control the flash mode, flash output, focal length, number of stroboscopic and stroboscopic frequency of YN560Li/YN720/YN685/YN560 III/YN560 IV/YN660. Ultrafast Charging Recycle System, Support Real-time Display of
Battery Remaining Capacity: At full power, the charging recycle time is just approx. 2s. Real-time display of battery remaining capacity is convenient for you to learn the status of charge.
Firmware Upgrade: The speedlite is equipped with USB port. To keep the best performance and compatibility of the speedlite, please download the latest firmware form the official YONGNUO website and update it. GN58 at ISO100, 105mm: YN560Li is a 2.4G big-index wireless speedlite which supports M/Multi/--mode.
Support Electric Zoom Function: The speedlite supports manual zoom. The flash coverage range is 24-105mm. Support S1 and S2 avoid pre-flash optical triggering mode; Support auto-save setting, custom setting(Fn. ) and power saving function; Equipped with sound prompt system, indicates flash working status with different sound; Equipped with LCD display screen, standard PC sync port.
