|German Equatorial Mount
|Computerized with 40,000 Accessible Objects
|Latitude Range: 15° - 70°
|NexStar+ Hand Control
|Dual Vixen/Losmandy Dovetail Saddle
|All-Star Polar Alignment
. - Allows To Align On Any 3 Bright Celestial Objects
. - Making Fast & Easy Alignment Process
|Steel Leg Tripod
|Dual-Axis Low-Cog DC Servo Motor
.
.
Specifications:
.
.
| Mount: German Equatorial
| Tripod: 2? Steel Tripod with Graduated Markings on Lower Section
| Dovetail Mount: Directly Connects to Both CG-5 & CGE Dovetail Bars
| Payload Capacity: 40 lbs
| Latitude Range: 15° - 70°
| Power Requirements: 12 VDC, 3.2 amps
| Ports: 1x Hand control port, 1x Auxiliary Port, 1x Auto Guider Port, 1 USB 2.0
Port (on hand control)
| Motor Drive: Low Cog DC Servo Motors
| Slew Speeds: 9 Slew Speeds
| Tracking Rates: Sidereal, Solar and Lunar
| Tracking Modes: EQ North and EQ South
| Alignment Procedures: AutoAlign, 2-Star Align, Quick Align, 1-Star Align, Last
Alignment, Solar System Align
| Computerized Hand Control: Double line, 16 character Liquid Crystal Display; 19
Fiber Optic Backlit LED buttons, USB 2.0 Port for PC Connection
| Database: 40,000+ objects, 100 User Defined Programmable Objects. Enhanced
Information on over 200 Objects
| Mount Weight: 40 lbs
| Tripod Weight: 20 lbs
| Weight of Counterweight: 17 lbs Counterweight
| Total Weight of Mount Kit: 77 lbs
. .
