Elation KL CORE IP | 400W RGBMA LED - 15,588 lm | IP65 Ellipsoidal & Fresnel Hybrid

IP65 Full-Spectrum LED Light Engine for Ellipsoidal, Fresnel & Broadcast Use

The Elation KL CORE IP is a powerful and adaptable 400W RGBMA LED lighting engine designed for professional stage, film, and broadcast applications. Offering over 15,000 lumens of output, an IP65 rating, and multiple configuration optionsâ??including ellipsoidal, Fresnel, and monolightâ??this fixture delivers high-quality light and unmatched flexibility in any environment.

Elation KL CORE IP Competitive Differences

• 400W RGBMA LED engine with 15,588 lumens of output
• IP65-rated for all-weather indoor/outdoor use
• Fully homogenized light source for even beam performance
• Supports shutter barrel, Fresnel lens, and Bowens mount accessories
• High CRI of 94.9 and TLCI of 95 for true-to-life color rendering
• Built-in IP65 Gobo Rotator port and DMX/RDM support
• Touch bar encoder for easy stand-alone control
• Wireless configuration via Aria x2 and NFC
• Compatible with 3rd party ellipsoidal shutter barrels

Elation KL CORE IP Description

The KL CORE IP is the core lighting engine in Elationâ??s KL series, offering a future-proof and modular approach to professional lighting. Powered by a high-efficiency 400W RGBMA LED, the fixture delivers a stunning 15,588 lumens and supports a broad CCT range from 2400K to 8500K with full 16-bit control. Designed for maximum flexibility, it easily converts into an ellipsoidal spotlight with the optional KL CORE IP Shutter Barrel, a zoomable Fresnel with the KL CORE IP Fresnel Lens, or a monolight-style fixture with the KL CORE IP Bowens Mount.

The unit is engineered with a fully sealed housing thatâ??s IP65-rated, making it equally suited for outdoor and indoor applications while keeping internal components free of dust and debris. The advanced color mixing engine delivers both high brightness and high-fidelity modes with additional features like CMY emulation, dim-to-warm red shift, and a virtual gel library.

Control options are equally flexible, with 9 DMX channel modes, RDM, Aria x2 wireless device management, onboard NFC, and a user-friendly touch bar encoder for manual operation. An integrated IP65 connector supports optional gobo rotators, expanding its creative capabilities even further. This rugged, professional-grade fixture is ideal for theatrical productions, concerts, live events, broadcast studios, and architectural installs.

KL CORE IP Features

• 400W RGBMA Full-Spectrum LED Engine
• 15,588 lumen output (integrating sphere)
• IP65-rated for outdoor/indoor use
• CRI 94.
