RCF NX 912SMA | 12in - 2100W | Stage Monitor Active Wedge with BMC & FiRPHASE

Touring-Grade Stage Monitor and Multi-Purpose Active Speaker The RCF NX 912-SMA is a premium active stage monitor and FRFR solution designed for demanding performers, musicians, DJs, and audio professionals. Featuring a 12â?� woofer, 1.75â?� compression driver, and a 2100W Class-D amplifier, it delivers up to 130â?¯dB SPL of clean, distortion-free audio. Its low-profile wedge design, pole mount capability, and DSP enhancements like FiRPHASE and Bass Motion Control (BMC) ensure powerful, consistent sound whether used on stage or as a standalone main speaker. RCF NX 912-SMA Competitive Differences

• FRFR-ready with 0° phase response for amp modelers and multi-FX users
• 12" woofer and 1.75â?� HF driver powered by dual 2100W Class-D amplification
• Flexible horizontal and vertical deployment with TRW waveguide

RCF NX 912-SMA Description Tailored for high-impact touring, the NX 912-SMA features a rugged birch plywood enclosure, convection-cooled amplifier, and steel grille for durability on the road. The compact footprint is perfect for tight stage setups, and pole-mount support adds main speaker versatility. RCFâ??s proprietary Bass Motion Control DSP manages low-frequency performance without affecting phase or linearity. The FiRPHASE filtering delivers a flat, time-aligned response for clear, intelligible monitoring. Its advanced TRW (True Resistive Waveguide) horn provides a wide 100° x 70° coverage pattern with controlled directivity and reduced HF distortion. Perfect for modern guitarists using amp modelers, the NX 912-SMAâ??s Full Range Flat Response (FRFR) performance accurately reproduces detailed, complex tonal signatures across your presets. Combined with its power and headroom, this makes it an excellent alternative to traditional guitar or bass cabs. Model Features

• 2100W Class-D bi-amplification (1400W LF + 700W HF)
• 12" woofer with 2.5" voice coil for tight, extended bass
• 1.75â?� neodymium compression driver with TRW horn
• 100° x 70° coverage with consistent off-axis response
• FiRPHASE DSP for linear phase response
• Bass Motion Control excursion management
• FRFR optimized response for amp modelers
• True Outdoor Protection powerCON TRUE1 TOP connectors
• Low-profile plywood cabinet with pole mount and handles

Model Specifications

• Max SPL: 130â?¯dB
• Frequency Response: 50â?¯Hz â?? 20,000â?¯Hz
• Crossover Frequency: 1600â?¯Hz
• Coverage Pattern: 100° H x 70° V
• Transducers: 12" woofer (2.5" VC), 1.75" compression driver
• Input: Combo XLR/¼" TRS, Output: XLR
• Power Input: powerCON TRUE1 TOP In/Out
• Controls: Volume, internal limiter and protection
• Enclosure: Touring-grade plywood with steel grille
• Dimensions: 12.6 x 24.41 x 15.51 in (320 x 620 x 394 mm)
• Weight: 44.09 lb (20 kg)

What's In The Box

• RCF NX 912-SMA Active Monitor
• PowerCON TRUE1 TOP Cable
• User Manual
