| Module Size |
Module:30*15*5.2mm FPC:171.5*30*24.03mm |
| Sensor |
1/1.8-Inch IMX678-AAQR1-C |
| Resolution |
3840H x 2160V |
| Pixel Size |
2.0*2.0µm |
| Output Format |
MJPEG, YUV2 , |
| FOV |
DFOV:92° HFOV:85° VFOV:54° |
| Lens |
M12 P0.5 3G+3P IR 650NM |
| TV distortion |
<0.5% |
| FEL |
4.2 |
| F/NO |
2.0 |
| CAR |
12.3° |
| Focus Type |
FF |
| Shutter Type |
Electronic rolling shutter |
| Output and Power Supply |
High Speed USB2.0 |
| Interface |
5P 1.0MM |
| Controllable Parameters |
Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White Balance, Backlight Contrast, Exposure |
| Supported OS |
Windows10,Windows11, Android, Linux, |
| Cable Length |
1m |
Supported Resolution and Frame Rate
| Format |
Resolution |
Frame Rate (USB2.0) |
| MJPG |
3840x2160(4K) |
30FPS |
|
|
2560x1440(2K) |
30FPS |
|
|
2592x1944(5MP) |
30FPS |
|
|
2048x1536(3MP) |
30FPS |
|
|
1600x1200(2MP) |
30FPS |
|
|
1920x1080 (1080P) |
30FPS |
|
|
1280x720 (720P) |
30FPS |
|
|
640x480 (VGA) |
30FPS |
| YUY2 |
3840x2160(4K) |
1FPS |
|
|
2560x1440(2K) |
1FPS |
|
|
2592x1944(5MP) |
1FPS |
|
|
2048x1536(3MP) |
2FPS |
|
|
1600x1200(2MP) |
3FPS |
|
|
1920x1080 (1080P) |
5FPS |
|
|
1280x720 (720P) |
10FPS |
|
|
640x480 (VGA) |
30FPS |
| Operating Voltage |
USB DC +5V Supply |
| Operating Current |
180mA |
| Operating Temperature |
-15? ~ 60? |
| Storage Temperature |
-20? ~ 85? |
| Humidity |
80 ~85% |
