AC 70-1000V 3 Phase Rotation Meter, ETCR1000C Non Phase Sequence Detector Magnetic Base Phase Meter

Exquisite Design: The bottom of the phase shifter is equipped with four magnets, which can be easily attached to the metal casing of the equipment during testing and seamlessly connected anywhere
Easy To Operate: Clamp type non sensitive measurement, no need to touch the high-voltage exposed live wire, directly clamp three super sensitive high insulation clamps on the insulation skin of the three-phase live wire to detect phase sequence

Specification:
ModelETCR1000C
FunctionsPhase detection (Positive phase, reverse phase and phaseloss), Live wire examination, Simple Power detection, Breakpoint location and Line maintenance.
Power SupplyDC 3V2*AA dry battery, Continuously working for 70 hours
AC Voltage Range (V) AC 70 - 1000V, 40/65Hz
Clamp Wire SizeExternal Diameter 1.6 -16mm
LED Display
(Positive Phase Sequence)
The four phase-sequence lamps light in order (clockwise).
(Negative Phase Sequence)
The four phase-sequence lamps light in order (counterclockwise).
(Live Power) L1, L2, L3 lamp light up in the voltage setting range.
(Phase Loss) L1 or L2 or L3 does not light.
(Short Circuit) L1 or L2 or L3 does not light.
Buzzing
(Positive phase) The instrument emits intermittent short beeps;
(Reverse phase) The instrument emits a continuous long beep.
Power On IndicationPower on indication light turns on; Low power, low battery light on
Magnetic forceFour magnets on the back of the meter, which are attached to the distribution box and can withstand 800g quality.
Auto Power offAfter 5 minutes, the meter automatically cut off power supply.
Meter DimensionWidth, height, thickness 70mm*75mm*30mm
Clamp Lead Length 0.6 m
Weight317g
Working Temperature and Humidity-10-55; below 80%rh
Storage Temperature and Humidity-20-60; below 90%rh
Maximum Measured VoltageAC 1000V
Dielectric Strength 5.4 kVrms
Maximum rated Power100mVA
Safety ProvisionsEN61010- 1: 2001, EN61010- 031: 2002, Pollution level 2, CAT 3 (600V), Transient over-voltage 6000V
Package list:
1 * Phase Sequence Detector
1 * User Manual
Note:
The actual product color may deviate from the photo due to light.
There may be a slight deviation in the measurement of product.
