HP 5120-24G Switch (JE068A)

Specs: Capacity
Type: IPv4 routing table entries
Value: 32 Chassis Installed Devices
Modules Qty: 0 Supported Devices
Modules Qty: 2 Dimensions &
Weight Depth: 11.8 in
Height: 1.7 in
Weight: 9.9 lbs
Width: 17.3 in Environmental Parameters
Humidity Range Operating: 10 - 90% (non-condensing)
Humidity Range Storage: 5 - 95% (non-condensing)
Max Operating Temperature: 113 °F Max
Storage Temperature: 158 °F
Min Operating Temperature: 32 °F Min
Storage Temperature: -40 °F Flash
Memory Installed Size: 16
MB Type: Flash
Header Brand: HP
Compatibility: PC
Manufacturer: ProCurve
Networking Model: 5120-24G EI Switch with 2 Interface
Slots Packaged Quantity: 1
Product Line: HP
Interface Provided Connector Type: RJ-45
Qty: 24
Type: 1000Base-T
Comments: Management
Qty: 1
Type: Console
Connector Type: SFP
Connector Type: SFP (mini-GBIC)
Qty: 4
Miscellaneous Authentication Method: HWTACACS, RADIUS, Secure Shell (SSH), Secure Shell v. 2 (SSH2), TACACS, TACACS+
Compliant Standards: ANATEL, ANSI C 63.4 -2003, CISPR 22 Class A, CSA C 22.2 No. 60950-1, EMC, EN 60825-1, EN 60825-2, EN 60950-1, EN 61000-3-2, EN 61000-3- 2:2006, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN300-386, EN55022 Class A, FCC CFR47 Part 15, FCC Class A certified, FCC Part 15, GOST, ICES-003 Class A, IEC 60950-1, NOM, RoHS, UL 60950-1, VCCI Class A ITE, WEEE
Encryption Algorithm: SSL
Height (Rack Units): 1 Rack
Mounting Kit: Included Networking
Cabling Type: Ethernet 1000Base-T, Ethernet 100Base-TX, Ethernet 10Base-T
Communication Mode: Full-duplex
Compliant Standards: IEEE 802.1 ab (LLDP), IEEE 802.1 ad, IEEE 802.1D, IEEE 802.1 p, IEEE 802.1Q, IEEE 802.1 w, IEEE 802.1 x, IEEE 802.3, IEEE 802.3 ab, IEEE 802.3 ad (LACP), IEEE 802.3 i, IEEE 802.3 u, IEEE 802.3 x, IEEE 802.3 z
Connectivity Technology: Wired
Empty Slots: 4 x shared SFP (mini-GBIC) / 2 x
Expansion Slot Features: Access Control List (ACL) support, ARP support, Auto-uplink (auto MDI/MDI-X), BOOTP support, Committed Access Rate (CAR), Device Link Detection Protocol (DLDP) support, DHCP protection, DHCP support, Dynamic ARP protection, Endpoint Admission Defense (EAD), Flow control, IGMP snooping, IPv4 support, IPv6 support, Jumbo Frames support, Layer 2 switching, Layer 3 switching, LLDP support, MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Port isolation, Port Security, Quality of Service (QoS), Rapid Ring Protection Protocol (RRPP) support, Rapid Spanning Tree Protocol (RSTP) support, Routing, sFlow, STP Root Guard, Strict Priority (SP), VLAN support, Weighted Round Robin (WRR) queuing
Form Factor: Rack-mountable, Rack-mountable Jumbo
Frame Support: 9216 bytes
MAC Address Table Size: 16K entries
Manageable: Yes
Ports Qty: 24
Remote Management Protocol: CLI, HTTP, HTTPS, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, SSH, SSH-2, Telnet
Routing Protocol: Static IPv4 routing, Static IPv6 routing
Stackable: Stackable
Subcategory: Network hubs and switches
Subtype: Gigabit
Ethernet Switching Protocol: Ethernet
Type: Switch
Performance Type: Routing/switching capacity
Value: 144
Gbps Type: Throughput
Value: 107.2 Mpps
Ports Qty: 24
Type: 10/100/1000
Ports (2nd) Qty: 4
Type: Shared Gigabit SFP
RAM Installed Size: 128
MB Technology: SDRAM
Slot Provided Free Qty: 2
Total Qty: 2
Type: Expansion slot
