Dell H784T Managed L3 Switch 48X10Gigabit SFP+ Ports

DELL H784T Networking N3048 - Switch - 48 Ports - Managed - Rack-mountable.

Key Features:


Device Type: Switch - 48 Ports - L3 - Managed - Stackable

Enclosure Type: Rack-mountable 1u

Subtype: Gigabit Ethernet

Ports: 48 X 10/100/1000 + 2 X 10 Gigabit Sfp+ + 2 X Combo 1000base-t

Performance: Switching
Fabric Bandwidth: 260
Gbps ¦ Forwarding Performance: 193 Mbps ¦ Stacking Bandwidth: 84 Gbps

Capacity: Mac
Addresses: 32000
¦ Ipv4 Routes (static): 1024
¦ Ipv6 Routes (static): 1024
¦ Ipv4 Routes (dynamic): 8160
¦ Ipv6 Routes (dynamic): 4096 ¦ Maximum Member Ports Per Lag: 8 ¦ Maximum Dynamic Ports Per Switch Stack: 144
¦ Lag Groups: 128
¦ Ospf Routes: 8160
¦ Rip Routes: 512 ¦ Ecmp Next Hops Per Route: 4
¦ Ecmp Groups: 64
¦ Vlan Routing Interfaces: 128
¦ Vlans Supported: 4094
¦ Multicast Entries (ipv4): 1536
¦ Multicast Entries (ipv6): 512
¦ Arp Entries: 6144
¦ Ndp Entries: 400
¦ Acl: 100
¦ Maximum Rules Per Acl: 1023
¦ Max Acl Rules System-wide: 4096 ¦ Maximum Acl Rules Per Interface (ipv4)
Egress Rules: 1024 ¦ Maximum Acl Rules Per Interface (ipv4)
Ingress Rules: 3072 ¦ Maximum Acl Rules Per Interface (ipv6)
Egress Rules: 512 ¦ Maximum Acl Rules Per Interface (ipv6)
Ingress Rules: 1021 ¦ Maximum Vlan Interfaces With Acls Applied: 24

Mac Address Table Size: 32k Entries

Routing Protocol: Ospf, Rip-1, Rip-2, Igmpv2, Igmp, Vrrp, Ospfv2, Pim-sm, Pim-dm, Igmpv3, Ospfv3, Mldv2, Mld

Remote Management Protocol: Snmp 1, Snmp 2, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Snmp 3, Http, Ssh-2

Encryption Algorithm: Md5, Aes, Ssl, Tls

Authentication Method: Radius, Tacacs+, Secure Shell V. 2 (ssh2)

Features: Flow Control, Layer 3 Switching, Layer 2 Switching, Mdi/mdi-x Switch, Auto-negotiation, Load Balancing, Port Mirroring, Stackable, Weighted Round Robin (wrr) Queuing, Broadcast Storm Control, Rapid Spanning Tree Protocol (rstp) Support, Multiple Spanning Tree Protocol (mstp) Support, Access Control List (acl) Support, Quality Of Service (qos), Port Forwarding, Stp Root Guard, Lldp Support, Link Aggregation Control Protocol (lacp), Per-vlan Rapid Spanning Tree (pvrst), Energy Efficient Ethernet, Dynamic Vlan Support (gvrp), Dual Firmware Images, Network Access Control (nac), Tagged Vlan, Generic Vlan Registration Protocol (gvrp), Redundant Fans, Protocol-based Vlans Support

Compliant Standards: Ieee 802.2, Ieee 802.3, Ieee 802.3 u, Ieee 802.3 z, Ieee 802.1 d, Ieee 802.1 q, Ieee 802.3 ab, Ieee 802.1 p, Ieee 802.3 x, Ieee 802.3 ad (lacp), Ieee 802.1 w, Ieee 802.1 x, Ieee 802.3 ae, Ieee 802.3 ac, Ieee 802.1 s, Ieee 802.1 v, Ieee 802.1 ag, Ieee 802.1 ab (lldp), Ieee 802.3 az

Ram: 1 Gb

Flash Memory: 256 Mb

Expansion / Connectivity:

Interfaces: 48 X Gigabit Lan - Rj-45 ¦ 2 X 10gbit Lan - Sfp+ ¦ 2 X Gigabit Lan - Rj-45 ¦ 1 X Serial (rs-232) - Rj-45 - Management ¦ 1 X Usb - Type A ¦ 2 X Network Stack Device

Power:

Power Device: Internal Power Supply - Hot-plug

Installed Qty: 1 (installed) / 2 (max)

Power Redundancy: Optional

Power Redundancy Scheme: 1+1 (with Optional Power Supply)

Power Provided: 200 Watt

Power Consumption Operational: 74.8 Watt
