Dell PDJ93 Networking Managed L3 Switch 24 Ethernet Ports

DELL PDJ93 N3024 Managed L3 Switch - 24 Ethernet Ports & 2 10-gigabit Sfp+ Ports & 2 Combo 1000base-t Ports.
Key Features: Device
Type: Switch - 24 Ports - L3 - Managed -
StackableEnclosure Type: Rack-mountable
- 1uSubtype: Gigabit
EthernetPorts: 24 X 10/100/1000 + 2 X 10 Gigabit Sfp+ + 2
X Combo 1000base-tPerformance: Switching
Fabric Bandwidth: 212
Gbps Forwarding Performance: 158
Mbps Stacking Bandwidth: 84
GbpsCapacity: Mac
Addresses: 16384 Ipv4
Routes (static): 1024 Ipv6
Routes (static): 1024 Ipv4
Routes (dynamic): 8160 Ipv6
Routes (dynamic): 4096 Maximum Member
Ports Per Lag: 8 Maximum Dynamic Ports Per Switch Stack: 144
Lag Groups: 128
Ospf Routes: 8160
Rip Routes: 512
Ecmp Next Hops Per Route: 4
Ecmp Groups: 64
Vlan Routing Interfaces: 128
Vlans Supported: 4094
Multicast Entries (ipv4): 512
Multicast Entries (ipv6): 256
Arp Entries: 6144
Ndp Entries: 400
Acl: 100
Maximum Rules Per Acl: 1023
Max Acl Rules System-wide: 4096 Maximum Acl Rules Per Interface (ipv4)
Egress Rules: 1024 Maximum Acl Rules Per Interface (ipv4)
Ingress Rules: 3072 Maximum Acl Rules Per Interface (ipv6)
Egress Rules: 512 Maximum Acl Rules Per Interface (ipv6)
Ingress Rules: 1021 Maximum Vlan Interfaces With Acls Applied: 24Mac
Address Table Size: 16k
EntriesRouting Protocol: Ospf, Rip-1, Rip-2, Igmpv2, Igmp, Vrrp, Pim-sm, Pim-dm, Igmpv3, Ospfv3, Mldv2, MldRemote
Management Protocol: Snmp 2, Snmp, Rmon, Http, SshEncryption
Algorithm: Md5, Aes, Ssl, TlsAuthentication
Method: Secure Shell (ssh), Radius, Tacacs+Features: Flow Control, Layer 3 Switching, Layer 2 Switching, Mdi/mdi-x Switch, Auto-negotiation, Port Mirroring, Stackable, Weighted Round Robin (wrr) Queuing, Broadcast Storm Control, Rapid Spanning Tree Protocol (rstp) Support, Multiple Spanning Tree Protocol (mstp) Support, Quality Of Service (qos), Port Forwarding, Lldp Support, Link Aggregation Control Protocol (lacp), Per-vlan Rapid Spanning Tree (pvrst), Energy Efficient Ethernet, Dynamic Vlan Support (gvrp), Dual Firmware Images, Network Access Control (nac), Tagged Vlan, Generic Vlan Registration Protocol (gvrp), Redundant Fans, Protocol-based
Vlans SupportCompliant Standards: Ieee 802.2, Ieee 802.3, Ieee 802.3 u, Ieee 802.3 z, Ieee 802.1 d, Ieee 802.1 q, Ieee 802.3 ab, Ieee 802.1 p, Ieee 802.3 x, Ieee 802.3 ad (lacp), Ieee 802.1 w, Ieee 802.1 x, Ieee 802.3 ae, Ieee 802.3 ac, Ieee 802.1 s, Ieee 802.1 v, Ieee 802.1 ag, Ieee 802.1 ab (lldp), Ieee
802.3 azRam: 1
GbFlash Memory: 256 MbExpansion /
Connectivity:
Interfaces: 24 X Gigabit Lan - Rj-45 2 X 10gbit Lan - Sfp+ 2 X Gigabit Lan - Rj-45 1 X Serial (rs-232) - Rj-45 - Management 1 X Usb - Type A 2
X Network Stack DeviceExpansion Slots: 1 (total) / 1 (free) X
Expansion SlotPower: Power
Device: Internal Power Supply -
Hot-plugInstalled Qty: 1 (installed) / 2 (max)
Power Redundancy: OptionalPower
Provided: 200 WattPower
Consumption Operational: 52.8 Watt
