DELL 9T7H3 Networking N1524 Switch 24
Ports Managed Rack-mountableKey Features: Device
Type: Switch 24
Ports L2+ Managed StackableEnclosure Type: Rack-mountable
1uSubtype: Gigabit
EthernetPorts: 24 X 10/100/1000 + 4 X 10
Gigabit Sfp+Performance: Switching
Fabric Bandwidth: 128
Gbps Forwarding Performance: 128
MppsCapacity: Virtual
Interfaces (vlans): 512
Arp Entries: 1024
Ndp Entries: 400
Priority Queues Per Port: 8 Ipv4
Routes (static): 256 Ipv6
Routes (static): 128 Ipv4
Routes (dynamic): 256
Vlan Routing Interfaces: 128
Acl: 100
Max Acl Rules System-wide: 2048
Maximum Rules Per Acl: 1023 Maximum Acl Rules Per Interface (ipv4)
Ingress Rules: 1023 Maximum Acl Rules Per Interface (ipv4)
Egress Rules: 1023 Maximum Acl Rules Per Interface (ipv6)
Ingress Rules: 512 Maximum Acl Rules Per Interface (ipv6)
Egress Rules: 509 Maximum Vlan Interfaces With Acls Applied: 24 Maximum Dynamic Ports Per Switch Stack: 144 Maximum Member
Ports Per Lag: 8
Mac Addresses: 16000Mac
Address Table Size: 16000
EntriesRouting Protocol: Rip-1, Rip-2, Static Ipv4 Routing, Static Ipv6 RoutingRemote
Management Protocol: Telnet, TftpEncryption
Algorithm: Md5, Aes, Ssl, TlsAuthentication
Method: Secure Shell (ssh), Radius, Tacacs+Features: Auto-negotiation, Auto-uplink (auto Mdi/mdi-x), Port Mirroring, Broadcast Storm Control, Redundant
FansRam: 1
GbFlash Memory: 256 MbExpansion /
Connectivity:
Interfaces: 24 X Gigabit Lan - Rj-454 X 10gbit Lan - Sfp+1 X Serial (rs-232) - Rj-45 - Management1 X Usb - Type A2 X
Network Stack DevicePower: Power
Device: Internal
Power SupplyInstalled Qty: 1Power
Provided: 40 WattPower
Consumption Operational: 30.2 Watt
