Dell M40JD N4064 48X10Gbase-T And 2X40Gbe Switch

DELL M40JD Networking N4064 Switch 48 Ports Managed Rack-mountable With Dual
Power And Rails: Key
Features: Device
Type: Switch - 48 Ports - L3 - Managed -
StackableEnclosure Type: Rack-mountable
1uSubtype: 10
Gigabit EthernetPorts: 48 X 10 Gigabit Ethernet + 2 X 40
Gigabit Qsfp+Performance: Switching
Fabric Bandwidth: 1.28
Tbps Forwarding Performance: 952
MppsCapacity: Mac
Addresses: 131072 Ipv4
Routes (static): 1024 Ipv6
Routes (static): 1024 Ipv4
Routes (dynamic): 8160 Ipv6
Routes (dynamic): 4096 Maximum Member
Ports Per Lag: 8 Maximum Dynamic Ports Per Switch Stack: 144
Lag Groups: 128
Priority Queues Per Port: 8
Ospf Routes: 8160
Rip Routes: 512
Ecmp Next Hops Per Route: 4
Ecmp Groups: 1024
Vlan Routing Interfaces: 128
Vlans Supported: 4094
Multicast Entries (ipv4): 512
Multicast Entries (ipv6): 256
Arp Entries: 6144
Ndp Entries: 400
Acl: 100
Maximum Rules Per Acl: 1023
Max Acl Rules System-wide: 3072 Maximum Acl Rules Per Interface (ipv4)
Egress Rules: 1023 Maximum Acl Rules Per Interface (ipv4)
Ingress Rules: 2047 Maximum Acl Rules Per Interface (ipv6)
Egress Rules: 512 Maximum Acl Rules Per Interface (ipv6)
Ingress Rules: 1021 Maximum Vlan Interfaces With Acls Applied: 24Mac
Address Table Size: 131072
EntriesRouting Protocol: Ospf, Rip-1, Rip-2, Igmpv2, Igmp, Vrrp, Ospfv2, Pim-sm, Pim-dm, Igmpv3, Ospfv3, Mldv2, MldRemote
Management Protocol: Snmp 2, Snmp, Rmon, Http, SshEncryption
Algorithm: Aes, Ssl, Tls 1.0A uthentication
Method: Radius, Tacacs+, LdapFeatures: Layer 3 Switching, Layer 2 Switching, Mdi/mdi-x Switch, Auto-negotiation, Port Mirroring, Stackable, Broadcast Storm Control, Ip Address Filtering, Access Control List (acl) Support, Quality Of Service (qos), Dynamic Arp Inspection (dai), Lldp Support, Remote Switch Port Analyzer (rspan), Management Information Base (mib), Dual Firmware Images, Redundant Fans, Mac And Ip-based Acls Support, Time-controlled Acls Support, Protocol-based
Vlans SupportCompliant Standards: Ieee 802.2, Ieee 802.3, Ieee 802.3 u, Ieee 802.3 z, Ieee 802.1 d, Ieee 802.1 q, Ieee 802.3 ab, Ieee 802.1 p, Ieee 802.3 x, Ieee 802.3 ad (lacp), Ieee 802.1 w, Ieee 802.1 x, Ieee 802.3 ae, Ieee 802.3 ac, Ieee 802.1 s, Ieee 802.1 v, Ansi/tia-1057, Ieee 802.1 ag, Ieee 802.1 ab (lldp), Ieee 802.3 az, Ieee 802.1 qbb, Ieee
802.1 qazRam: 2
GbFlash Memory: 256 MbExpansion /
Connectivity:
Interfaces: 48 X 10gbit Lan - Rj-452 X 40gbit Lan - Qsfp+1 X Gigabit Lan - Rj-45 - Management1 X Serial (rs-232) - Rj-45 - Management1 X Usb -
Type AExpansion Slots: 1 (total) / 1 (free) X
Expansion SlotPower: Power
Device: Internal Power Supply -
Hot-plugInstalled Qty: 2 (installed) / 2 (max)
Power Redundancy: YesPower
Provided: 460 WattPower
Consumption Operational: 395
WattCondition:
RefurbishedAvailability: In
StockOur Warranty: 30 Days.
