Dell EMC PowerSwitch N3224F-ON - switch - 24 ports - managed - rack-mountable

DELL Emc Powerswitch N3224F-ON - Switch - 24 Ports - Managed -
Rack-mountable: Key
Features: Device
Type: Switch - 24 Ports - L3 - Managed -
StackableEnclosure Type: Front To Back Airflow Rack-mountable 1uSubtype: 10
Gigabit EthernetPorts: 24 X Gigabit Sfp + 4 X 10 Gigabit Sfp+ + 2 X 100
Gigabit Qsfp28Performance: Switching
Capacity: 528
Gbps ¦ Forwarding Rate: 733
MppsCapacity: Ipv4
Routes (static): 1024 ¦ Ipv6
Routes (static): 1024 ¦ Ipv4
Routes (dynamic): 8160 ¦ Ipv6
Routes (dynamic): 4096 ¦ Maximum Member
Ports Per Lag: 8 ¦ Maximum Dynamic Ports Per Switch Stack: 144
¦ Lag Groups: 128
¦ Ospf Routes: 8158
¦ Rip Routes: 512 ¦ Ecmp Next Hops Per Route: 16
¦ Ecmp Groups: 1024
¦ Vlan Routing Interfaces: 128
¦ Vlans Supported: 4094
¦ Multicast Entries (ipv4): 1023
¦ Multicast Entries (ipv6): 1021
¦ Arp Entries: 6144
¦ Ndp Entries: 2560
¦ Acl: 100
¦ Maximum Rules Per Acl: 1023
¦ Max Acl Rules System-wide: 3914 ¦ Maximum Acl Rules Per Interface (ipv4)
Egress Rules: 511 ¦ Maximum Acl Rules Per Interface (ipv4)
Ingress Rules: 1023 ¦ Maximum Acl Rules Per Interface (ipv6)
Egress Rules: 506 ¦ Maximum Acl Rules Per Interface (ipv6)
Ingress Rules: 1021 ¦ Maximum Vlan Interfaces With Acls Applied: 24Mac
Address Table Size: 32k
EntriesRouting Protocol: Ospf, Rip, Rip-2, Igmpv2, Igmp, Ospfv2, Igmpv3, Ospfv3, Ipv4-to-ipv6 MulticastRemote
Management Protocol: Snmp 1, Snmp 2, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Telnet, Snmp 3, Http, Tftp, Ssh-2Encryption
Algorithm: Md5, Aes, Ssl, TlsAuthentication
Method: Radius, Tacacs+, Secure Shell V.
2 (ssh2) Features: Flow Control, Mdi/mdi-x Switch, Auto-negotiation, Arp Support, Vlan Support, Port Mirroring, Diffserv Support, Weighted Round Robin (wrr) Queuing, Broadcast Storm Control, Ipv6 Support, Rapid Spanning Tree Protocol (rstp) Support, Multiple Spanning Tree Protocol (mstp) Support, Access Control List (acl) Support, Quality Of Service (qos), Stp Root Guard, Ipv4 Support, Lldp Support, Link Aggregation Control Protocol (lacp), Energy Efficient Ethernet, Management Information Base (mib), Dynamic Vlan Support (gvrp), Dual Firmware Images, Network Access Control (nac), Neighbor Discovery Protocol (ndp), Tagged Vlan, Redundant Fans, Protocol-based
Vlans SupportCompliant Standards: Ieee 802.2, Ieee 802.3, Ieee 802.3 u, Ieee 802.3 z, Ieee 802.1 d, Ieee 802.1 q, Ieee 802.3 ab, Ieee 802.1 p, Ieee 802.3 x, Ieee 802.3 ad (lacp), Ieee 802.1 w, Ieee 802.1 x, Ieee 802.3 ae, Ieee 802.3 ac, Ieee 802.1 s, Ieee 802.1 v, Ieee 802.1 ag, Ieee 802.1 ab (lldp), Ieee 802.3 az, Ieee
802.3 axRam: 4
GbFlash Memory: 8 GbExpansion /
Connectivity:
interfaces: 24 X Gigabit Lan Sfp ¦ 4 X 10gbit Lan Sfp+ ¦ 1 X 10/100/1000 Base-t Rj-45 Management ¦ 2 X 100gbit Lan Qsfp28 Stacking ¦ 1 X Usb Type A ¦ 1 X Micro-usb 2.0 Type B Console ¦ 1 X Serial (rs-232)
Rj-45 ConsolePower: Power
Device: Internal Power Supply -
Hot-plugInstalled Qty: 1Max
Supported Qty: 2Power
Redundancy: OptionalPower
Redundancy Scheme: 1+1 (with Optional Power Supply)
Power Provided: 550 WattPower
Consumption Operational: 224
Watt80 Plus Certification: 80 Plus Platinum
