HPE Aruba Switch 8320 48 Port 10/6 40 X472 5 2 Bundle (JL479A)

Interfaces:


48 x 10Gbit LAN SFP+


6 x 40Gbit LAN QSFP+


1 x serial RJ-45


1 x console (micro-USB)


1 x RJ-45


Device Type:


Switch - 48 ports - L3 - managed - with 2 x Aruba X371 400W AC Power Supply, 5 x Aruba X721 Front-to-Back Fan, Aruba X472 2-post Rack Kit

Enclosure Type:


Rack-mountable 1U


Ports:


48 x 10 Gigabit SFP+ + 6 x 40 Gigabit QSFP+

Performance:


Switching capacity: 2.5 Tbps


Forwarding performance: 1.905 Mpps

Capacity:


Virtual interfaces (VLANs) per port for 802.1q: 4096

Jumbo Frame Support: 9KB

Routing Protocol:


OSPF, IGMPv2, IGMP, VRRP, IGMPv3, GRE, static IPv6 routing, ECMP

Remote Management Protocol:


SNMP, RMON, SNMP 3, SNMP 2c, TFTP, SFTP

Encryption Algorithm: FIPS 140-2

Authentication Method:


RADIUS, TACACS+, Secure Shell v.2 (SSH2)

Features:


VPN support, IPv6 support, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4 support, Link Aggregation Control Protocol (LACP), redundant hot swappable fans, packet storm protection, Strict Priority (SP), Loopback, Bridge protocol data unit (BPDU), Multi-Chassis Link Aggregation (MLAG), Protocol Independent Multicast (PIM)

Compliant Standards:


IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1t, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3ba, IEEE 802.1AX


Aruba 8320 48p 10G SFP/SFP+ and 6p 40G QSFP+ with X472 5 Fans 2 Power Supply Switch Bundle

Includes 2 Power Supplies (JL480A) with No open PS slots

Includes 5 Fan Tray Bundles (JL481A) with No open FT Slots

Includes 1 2-Post Rack Kit (JL482B)

Min=0 \ Max= 48 SFP/SFP+ 1/10G Transceivers Min=0 \ Max = 6 QSFP+ 40G Transceiver

QSA28 Adapter Min=0 \ Max=6 (rule5) 1U Height
