4 Port 3.0 to PCIe Expansion Card PCI Express PCI-E Adapter PCI-e 3 Converter for HDD SSD IPFS Mining Controller

Laptop Network Adapters
4 port 3.0 to PCIe expansion Card PCI express PCI-E Adapter PCI-e 3 Converter for hdd SSD IPFS Mining Controller
About Description:
Feature:
1. With large heat sink, heat dissipation is better.2. The design of the rear four ports is more convenient to wire.3. Rear four port design, suitable for all kinds of chassis.4. The design of the tail edge, and the probability of blocking the card player is smaller.5. The four layer circuit board, with the addition of isolation layer in the middle, has anti-interference capability.6. mode selection, AHCL, IDE, data disk, three modes are free to choose.The three mode can be selected by pulling the switch:1. Hard disk boot system in AHQ mode.2. Data disk mode, hard disk does not participate in boot (at the same time can turn off self-test interface).3. Hard disk boot system in IDE mode.Specification:: H1111ZModel: SA3004Bus interface: PCI-EX1 ( with X4, X8, X16/ graphics card interface)Number of interfaces: SATA3.0 interface X4Product size: 120mm (baffle) *65mm*56mm/4.72*2.55*2.2''Product weight: 70gSystem support: support for Windows XP/2003/ Vista/win7/in8/win10 (32/64bit) operating system.Note:Please allow 1-3mm differs due to manual measurement.Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.
You'll receive:
1 x Adapter Card
1 x Low Profile Bracket
2 x Screws
Model Number : AC4557
Type : Hard Drive Adapters
Bus interface : PCI-E X1
Interfaces : SATA3.0 interface X4
Product size : 120mm (baffle) *65mm*56mm
