QSFPTEK Gigabit SFP Module 10G CWDM SFP+ Transceiver Module Single-Mode Fiber Mini GBIC Module, Plug and Play Transceiver for CWDM-SFP10G-1510 (1510nm 80km DOM)
- 100% CWDM-SFP10G-1470 COMPATIBLE SFP TRANSCEIVER:Compatible for CWDM-SFP10G-1470, wavelength: 1470nm, the transmission distance up to 40km.
- TECHNICAL SPECS: 10Gb/s data rate, duplex LC connector, cable type: SMF, working temperature: -5 ~ +70, Tx Power(dBm): -2 ~ 4, Rx Sens.(dBm): -15.8.
- EASY TO USE : Plug and play, hot-pluggable. Rotate the ring latch down at 90 degree angle to unlock, then pulling transceiver out from switch. Always keep the protective dust plug on the SFPs optical bores until you are ready to make a connection. MiniGBIC module with DDM allows you to monitor the critical information, to find out some potential problems.
- PREMIUM QUALITY: All of products are manufactured under strict quality control system, every module has been tested one by one on different switches before shipping, to ensure the compatibility. Hot-swappable in routers and switches
- OUTSTANDING SUPPORT: Backed by QSFPTEK Store for the life of the module itself, not your equipment; our module
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
10G CWDM 1470nm~1610nm SFP+ Transceiver Module
Data Rate: 10Gb/s
Reach: 80km
Source: EML+APD
Cable Type: Single-mode fiber (SMF)
Tx Power(dBm): -2 ~ +4
Rx Sens.(dBm): -24
Temperature: -5 ~ +70
DDM: with
Interface: LC duplex
Features:
Supports 9.95 to 11.3Gb/s bit rates, Duplex LC connector
Hot pluggable SFP+ footprint
Cooled 1470nm~1610nm EML transmitter, APD Receiver
Applicable for 80km SMF connection
Low power consumption, <1.5W
Digital Diagnostic Monitor Interface
Optical interface compliant to IEEE 802.3ae 10GBASE-ZR
Electrical interface compliant to SFF-8431
Operating Case Temperature Standard: 0ºC~+70ºC
Data Rate: 10Gb/s
Reach: 80km
Source: EML+APD
Cable Type: Single-mode fiber (SMF)
Tx Power(dBm): -2 ~ +4
Rx Sens.(dBm): -24
Temperature: -5 ~ +70
DDM: with
Interface: LC duplex
Features:
Supports 9.95 to 11.3Gb/s bit rates, Duplex LC connector
Hot pluggable SFP+ footprint
Cooled 1470nm~1610nm EML transmitter, APD Receiver
Applicable for 80km SMF connection
Low power consumption, <1.5W
Digital Diagnostic Monitor Interface
Optical interface compliant to IEEE 802.3ae 10GBASE-ZR
Electrical interface compliant to SFF-8431
Operating Case Temperature Standard: 0ºC~+70ºC
