SC Connector 1.25G Gigalight 1310nm/1550nm SFP 1.25G 3KM LC Optical Transceiver(1 Pair 3km LC)

Fiber Optic Products / Fiber Optic Receivers
SC Connector 1.25G Gigalight 1310nm/1550nm SFP 1.25G 3KM LC
1.25G 1310nm 1310/1550nm3KM LC/SC
General
Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (). They simultaneously comply with Gigabit Ethernet as specified in IEEE STD 802.3 and 1x Fibre Channel as defined in FC-PI-2 Rev. 10.0. They are compliant and lead-free.
It primarily enables bandwidth 1.25G optical links over single-mode fiber terminated with LC/SC simplex connectors and can be used in commercial temperature environment for interoperability with TTL Logic Interface.
Product Feature
1.25Gbps Data transfer rate
Tx1310nm/Rx1550nm andTx1550nm/Rx1310nmBiDi SFP
Distance up to 3km over SMF
Single 3.3V Power Supply and TTL Logic Interface
-Pluggable SFP
Simplex SC/LC (Optional)
Compliant with SFP
Digital Diagnostic Monitoring
Operating Case Temperature: 0-70 Temp
Application
Fiber Channel Links
WDM Application
Gigabit Ethernet
Other Optical Links
FTTX Application
SFP Transceiver
155M/622M SFP LC/SC
155M SFP LC/SC 3km/20km/40km/80km/120km with DDM optional
4/2/1G SFP LC/SC
4/2/1G SFP LC/SC 3km/20km/40km/80km/120km with DDM optional
10G SFP
SFP+ 1270 20km
SFP+ 20km Tx1270nm/Rx1330nm LC
SFP+ 1330 20km
SFP+ 20km Tx1330nm/Rx1270nm LC
SFP+ 1270 40km
SFP+ 40km Tx1270nm/Rx1330nm LC
SFP+ 1330 40km
SFP+ 20km Tx1330nm/Rx1270nm LC
SFP+ 1270 60km
SFP+ 60km Tx1270nm/Rx1330nm LC
SFP+ 1330 60km
SFP+ 60km Tx1330nm/Rx1270nm LC
10G XFP FP 1270 20km FPBiDi 20km Tx1270nm/Rx1330nm LC FP 1330 20km FP 20km Tx1330nm/Rx1270nm LC FP 1270 40km FPBiDi 40km Tx1270nm/Rx1330nm LC FP 1330 40km FP 40km Tx1330nm/Rx1270nm LC FP 1270 60km FPBiDi 60km Tx1270nm/Rx1330nm LC FP 1330 60km FP 60km Tx1330nm/Rx1
