3G SDI Bi-directional Video SFP Transceiver (1310nm Tx / 1550nm Rx & 1550nm Tx /1310nm Rx), 20Km (12.4 Miles) with MSA and DDM, Supports SMPTE Pathological Patterns
- Robust error free transmission of uncompressed signals, 20Km (12.4 Miles) over 1 Single Mode Fiber.
- Under worst-case conditions and 3Gbps video pathological signals
- Supports video pathological patterns for SD-SDI,HD-SDI and 3G-SDI
- Digital diagnostics (DDM) and control via I2C interface, hot pluggable.
+
+
Overview
Specs
Reviews
Any questions? Ask CelesteSM will help you find out quickly.
Try me now
CBP3D6-21-SDI & CBP5D6-21-SDI is one pair Bi-directional optical transceiver module designed to transmit and receive optical serial digital signals as defined in SMPTE 297-2006. They are specifically designed for robust performance in the presence of SDI pathological patterns for SMPTE 259M, SMPTE 344M,SMPTE 292M and SMPTE 424M serial rates.
Key parameters:
Bit Rate: 50M~2.97Gpbs
Transmitter wavelength:
CBP3D6-21-SDI: 1310nm DFB laser Tx/1550nm Rx
CBP5D6-21-SDI: 1550nm DFB laser Tx/1310nm Rx
Receive wavelength: 1260~1620nm
Output power: -5~0db
Sensi: -21db
DDM: Yes
Connector: 1 x LC
Distance: 20 Kilometers
Working temperature: 0~70'C
PIN assignment: MSA standard
Gross weight: 50g for 2 pieces
Package Contains:
1 x CBP3D6-21-SDI module
1 x CBP5D6-21-SDI module
Key parameters:
Bit Rate: 50M~2.97Gpbs
Transmitter wavelength:
CBP3D6-21-SDI: 1310nm DFB laser Tx/1550nm Rx
CBP5D6-21-SDI: 1550nm DFB laser Tx/1310nm Rx
Receive wavelength: 1260~1620nm
Output power: -5~0db
Sensi: -21db
DDM: Yes
Connector: 1 x LC
Distance: 20 Kilometers
Working temperature: 0~70'C
PIN assignment: MSA standard
Gross weight: 50g for 2 pieces
Package Contains:
1 x CBP3D6-21-SDI module
1 x CBP5D6-21-SDI module
