HL-SFP-16G-LR 16G 1310nm 10KM SFP+ LR FC Dual LC Transceivers(2 pcs)

Fiber Optic Receivers
HL-SFP-16G-LR 16G 1310nm 10KM SFP+ LR FC Dual LC Transceivers
16G 1310nm SFP+ 10KM
General
The HL-SFP-16G-LR Transceiver is intended for 10km service 14.025Gb/s 1310nm single mode high-speed communications equipment where low-cost, extraordinary performance and reliability are essential. It consumes low power, operates base on 3.3V DC power supply and is offered in the industrial temperature range. They are compliant with SFP+ , SFF-8431 and SFF-8432.
The low jitter and low bit error rate optical assembly features a DML laser transmitter and PIN/TIA receiver. The differential AC coupled Tx and Rx data interfaces are CML compatible. The device is Class I laser safety compliant.
Product Feature
Operating data rate up to 14.025Gbps
Up to 10km transmission distance
High sensitivityPinphotodiode and TIA
Rate Adaptation
LC duplex connector
pluggable 20pin connector
<;1.2W
Single +3.3V±5% power supply
Compliant with SFF-8472
Fully Compliant
Operating temperature range:
Commercial: 0°C to +70°C
Extended: -20°C to +85°C
Industrial: -40°C to +85°C
Application
Data Center Backbone
Ethernet Switches
High-speed Servers
High-performance Computing Clusters
SAN, Routers, Hubs, Load Balancer
Fiberchannel
Order information:

Part Number
Product Description
HLSF16GLRC
16G SFP+10km Transceivers, C-TEMP
HLSF16GLRE
16G SFP+10km Transceivers, E-TEMP
HLSF16GLRF
16G SFP+10km Transceivers, I-TEMP
