100G QSFP28 SR4 Fiber Optic Transceiver, 850nm MMF, OM3 70M/OM4 100M, Compatible QSFP28 Module, Made in Taiwan, 1pc
- Data Rate: 100Gb/s; Wavelength: 850nm; Connector: MTP/MPO
- Link distance 100m over OM4 fiber and 70m over MM OM3 fiber
- Compliant to SFF-8665 QSFP28 MSA; Data Rate 25.78125Gbps per Lane
- Wide Compatibility for Cisco, Juniper, and other open switches
- TAA compliant; Accept customized orders. Please tell us what brand and model name of host equipment you will apply. We need to know what coding to be input for you
+
+
Overview
Specs
Reviews
Any questions? Ask CelesteSM will help you find out quickly.
Try me now
100G QSFP28 SR4 Transceiver
Hot Pluggable, MPO / MTP, 850nm VCSEL, MMF 100M
Features
Compliant to IEEE802.3bm 100GBASE-SR4
Compliant to SFF-8665 QSFP28 MSA
Compliant to IEEE 802.3bm CAUI-4 Interface
4 independent full-duplex channels
Data Rate 25.78125Gbps per Lane
Built in quad TX CDR and RX CDR
Hot Pluggable QSFP28 footprint
4CH 850nm VCSEL array transmitter
4CH PIN array receiver
MPO-12 receptacle connector
2-wire interface for management and diagnostic monitor compliant with SFF-8636
Single 3.3V power supply
Link distance 100m over OM4 fiber and 70m over MM OM3 fiber
Maximum power consumption 2.5W
RoHS compliant
Applications
100GBASE-SR4 Ethernet @103.1G
Breakout to 4 x 25GBASE-SR Ethernet
Data Centers Switch Interconnect
Server and Storage Area Network Interconnect
