LFC-1000-SS SFP to SFP Slot multirate Fiber Media Converter, 155M to 2.5G speeds
- SFP to SFP slot Converter, any rate 155M to 2.5G supported, no rate conversion, completely transparent to protocol (Ethernet, Fiber Channel, SONET) forwards any size packets in transparent converter mode
- Speed (data rate) must be identical on both ports, supports Q in Q double tagged frame transparent and IEEE 802.1Q Tag VLAN pass thru, aggregates into LFC-CH12 series chassis available with various power supplies
- Optical interface: 2x SFP slot any rate 155M to 2.5G speed, full duplex; Fiber: Any type of fiber OM1, OM2, OM3, OM4 and OS1(MM 50/125m, 62.5/125m or SM 9/125m) as dictated by the SFPs used; Optical connector: LC connector for SFP modules (SFP transceivers NOT included); Front LEDs: PWR, SFP1, SFP2
- Power: External 90-260V AC switching adapter 12VDC@1A with NEMA1-15(2 blades only, US type main plug) included in carton package, Temperature: 0~50°C (Operating); -30~70°C (Storage), Humidity: 10-85% non condensing (Operating); 0-90% (Storage), Consumption: less than 4W
- Dime
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
SFP to SFP slot Converter, any rate 155M to 2.5G supported, no rate conversion, completely transparent to protocol (Ethernet, Fiber Channel, SONET) forwards any size packets in transparent converter mode
Speed (data rate) must be identical on both ports, supports Q in Q double tagged frame transparent and IEEE 802.1Q Tag VLAN pass thru, aggregates into LFC-CH12 series chassis available with various power supplies
Optical interface: 2x SFP slot any rate 155M to 2.5G speed, full duplex; Fiber: Any type of fiber OM1, OM2, OM3, OM4 and OS1(MM 50/125m, 62.5/125m or SM 9/125m) as dictated by the SFPs used; Optical connector: LC connector for SFP modules (SFP transceivers NOT included); Front LEDs: PWR, SFP1, SFP2
Power: External 90-260V AC switching adapter 12VDC@1A with NEMA1-15(2 blades only, US type main plug) included in carton package, Temperature: 0~50°C (Operating); -30~70°C (Storage), Humidity: 10-85% non condensing (Operating); 0-90% (Storage), Consumption: less than 4W
Dimensions(WxDxH): 60mm x 90mm x 20mm, Weight: 180g (without AC adapter), Compliance: FCC part 15, Subpart B, Class A, ANSI C63.4:2003 CE EN55022:2006, Class A EN55024:1998+A1:2001+A2:2003 LVD: EN 60 950-1:2001, MTBF: 65,000 hours
Speed (data rate) must be identical on both ports, supports Q in Q double tagged frame transparent and IEEE 802.1Q Tag VLAN pass thru, aggregates into LFC-CH12 series chassis available with various power supplies
Optical interface: 2x SFP slot any rate 155M to 2.5G speed, full duplex; Fiber: Any type of fiber OM1, OM2, OM3, OM4 and OS1(MM 50/125m, 62.5/125m or SM 9/125m) as dictated by the SFPs used; Optical connector: LC connector for SFP modules (SFP transceivers NOT included); Front LEDs: PWR, SFP1, SFP2
Power: External 90-260V AC switching adapter 12VDC@1A with NEMA1-15(2 blades only, US type main plug) included in carton package, Temperature: 0~50°C (Operating); -30~70°C (Storage), Humidity: 10-85% non condensing (Operating); 0-90% (Storage), Consumption: less than 4W
Dimensions(WxDxH): 60mm x 90mm x 20mm, Weight: 180g (without AC adapter), Compliance: FCC part 15, Subpart B, Class A, ANSI C63.4:2003 CE EN55022:2006, Class A EN55024:1998+A1:2001+A2:2003 LVD: EN 60 950-1:2001, MTBF: 65,000 hours
