Dpofirs 2 Ports Can Server Devices, 10 Port 100Mbps Network Can Al Ethernet Converter Module Interface Eth Industrial Grade IP Protocol for Computer

1. Hardware Protection The new hardware protection, CAN, serial port, network port and power supply have high-level protection, suitable for more demanding industrial environments; New ARM kernel, industrial-grade operating temperature range, carefully optimized IP protocol, stable and reliable.

2. Easy to use: 10 100Mbps network port, support for Auto MDI MDIX, can be used cross direct line; Support CAN ID filtering function, a variety of filtering methods to use more safely and conveniently; One port can support two SOCKET connections.

3. Simple configuration: CAN baud rate supports 10K~1Mbps; supports BASIC and LOOPBACK working mode; supports static IP address or DHCP to get IP address automatically and can query devices on the network via UDP transmission protocol; Reload one key to restore default settings, not afraid of wrong settings; RJ45 with data indicator link. RJ45 with Link Data indicator, external isolation transformer in network port, 1.5KV electromagnetic isolation.

4. Firmware Upgrade: The world's only media access control address (starting with D8 B0 4C); Support firmware update through the network, firmware update is more convenient; Support for web port (default 80); Support mechanism, can quickly detect idle connection and other anomalies and reconnect quickly.

5. Account Security: Support account and password, which can be used to login to the web and set up the network, more securely; Power supply interface supports terminal block 5.082 and wide voltage supply (5~36V); CAN relay function; CAN function to 485.



Specifications:

Item Type: 2 Port CAN to Ethernet Server

Material: Aluminum Alloy

Device interface: CAN RS485 ETH

Hardware:

Operating voltage: DC 5~36V

Working current:

26mA (Average) 36V

56mA (Average) 12V

124mA (Average) 5V

Power Guard: Power Surge Level 3, Group Pulse Level 3

Network port specification: RJ45, 10/100 Mbps, direct crossover
