Embedded LINUX RTOS ,dual core 32 bits DSP (TI Davinci DM368),
Pure hardware compression, watchdog,32M FLASH,128M DDR2
1/4" 1.0 Megapixel CMOS Image sensor.
Main Stream:1280×720
IR cut filter with auto switch, IR sensor.
Automatic image control functions:AWB,AGC,AEC,ABLC
Support WEB Configuration,IE Surveillance;
Support Dual Stream;
Support OSD,Chroma,Brightness,Saturation,Electric Zoom Configuration;
Support real-time transmission,Center warning and picture pop-up linkage supported ( after motion detection and IO alarm)
Support DDNS,UPNP remote control;Support Onvif 2.0;Support IR-Cut Switch,Sensible infrared;
Provide open SDK
Onvif 2.0
Water Resistance IP66 Rating
Board 4mm Fixed
3-Axis cable built-in bracket
Size: 148(W) x 65(H) x 63(D)mm
