Product Option:Horizontal Resolution:1000TVL,Signal System:PAL.Contact with us if you need other option.
Specification
Product Size:
Lens diameter 32MM
Intermediate thin section 25MM
The total length 30MM - 85MM adjustable
At the bottom of the thickest part of the 36MM
Horizontal resolution 1000 TV Lines,
No amount of infrared light (without IR)
Scanning frequency PAL: 15.625 kHz / 50 KHz
Scanning System 2: 1lnterlace, 2: 1 interlace
Internal Synchronization Internal / DC12V
Signal / noise ratio greater than 48dB Better than
Auto Auto Electronic Shutter 1/50 ~ 1 / 100,000 sec.
Video Output 1 Vp-p, 75 composite signal
Power supply 12V DC ( 10%)
1.7mm lens configuration
Power Consumption 800mA / DC12V
