| Video Compression |
H.265+ |
| IP Video Input |
8CH POE+2CH |
| Video Output |
HDMI Up to 4K |
| Audio Output |
Support |
| Max Recording Resolution |
Up to 8M(3860x2160) |
| Max Playback Resolution |
Up to 8M(3860x2160) |
| Max Playback Channel |
4CH |
| Max Playback Capacity |
4CH 3MP/2CH 5MP/1CH 8MP |
| Onvif |
Support |
| HDD |
1 SATA interface |
| HDD Capacity |
Up to 12TB capacity |
| Network interface |
RJ45x1(10/100/1000M) |
| PoE |
8 Ports(100Mbps, IEEE802.3at/af) |
| USB |
USB2.0x2 |
| Housing |
Metal for main part |
| Operating Power |
DC48V 2A |
| Power Consumption |
10W(without HDD);PoE: Max 30W for single port |
| Dimensions(W x H x D) |
260x245x47mm |
| Weight (without hard disk) |
820g(without HDD) |
Description:
8MP high definition live viewing & recording
8MP high definition playback channel
Support human detection
Vehicle shape detection, face capture (requires IPC support)
Up to 10 channels, 8 built-in PoE inputs
Advanced H. 265+ Video Compression
Support manual/alarm/motion detection/scheduled recording mode
Intelligent search and playback
Support alarm push and remote access
Support onvif protocol"
Video & Audio:
Video Compression: H. 265+
IP Video Input: 8CH POE+2CH
Video Output: HDMI Up to 4K
Audio Output: Support
Max Recording Resolution: Up to 8M (3860x2160)
Max Playback Resolution: Up to 8M (3860x2160)
Max Playback Channel: 4CH
Max Playback Capacity: 4CH 3MP/2CH 5MP/1CH 8MP
Onvif: Support
Hard Drive:
HDD: 1 SATA interface
HDD Capacity: Up to 12TB capacity
General:
Housing: Metal for main part
Operating Power: DC48V 2A
Power Consumption: 10W (without HDD)
PoE: Max 30W for single port
Working Temperature: 32 °F 131 °F /0 °C 55 °C
Dimensions (W x H x D): 260x245x47mm
Weight (without hard disk): 820g (without HDD)
Packaging Contents
NVR: 1
Power Adapter: 1
Ethernet Cable: 1m x1
USB Mouse: 1
AC power cable: 1
HDD Screw Pack: 4
Quick Start Guide: 1
Package Dimension (L x W x H): 350×80×275mm
Package Weight: 1.58K g (without HDD)
