FOR Delta AFB1212GHE-CF00 Case cooler

Model AFB1212GHE-CF00

Fan Counts 1 Fan

Type Case Fan

Compatibility Case

Fan Thickness 38mm

Bearing Type 2 Ball

RPM 5200 RPM

Air Flow 240.96 CFM

Noise Level 62 dBA

Power Connector 3 Pin

Color Black

Features

Features Rated Voltage: 12 VDC

Operating Voltage Range: 6 - 12.8 VDC

Input Current: 2.45 Amp (Maximum 3.24 Amp)

Input Power: 29.4W (Maximum 38.88W )

Maximum Air Pressure: 27.483 mm H2O

AFB1212GHE-CF00 high speed fan will give you incredible amount of air flow at a 120 x 120 x 38mm form factor. This DC fan can provide over 240 cubic feet of air out of a traditional design that has been highly refined over the years. The typical high pitched whine that accompanies most other directional fin fans has been minimized to near non-existence on this fan. It has an amazing, near 4:1 airflow to noise ratio, and yields 6.823 cubic meter of air per minute. Weighing at a hefty 0.73 pound, this premium grade cooling fans life expectance is 70, 000 hours (or almost 24 years if you operate the fan 8 hours a day) at 40 degree C with 15 - 65% RH, all thanks for industrial grade materials plus top notched, high quality dual ball bearing. This fan also features Over Current Shut Down function when rotor is locked during operation, thus effectively protects overheating and damaging of the fan. Operating temperature is -10 - +70 degree C with 5 - 90% RH.

Dimensions 120.00 x 120.00 x 38.00 mm
