Waveshare Industrial 8-Channel Relay Module for Raspberry Pi Pico Power Supply Isolation Photocoupler Isolation
- Onboard unibody power supply isolation, provides stable isolated voltage, needs no extra power supply for the isolated terminal | Onboard photocoupler isolation, prevent interference from external high-voltage circuit connected to the relay | High quality relay, contact rating: 10A 250V AC or 10A 30V DC. ABS protection enclosure with rail-mount support, easy to install, safe to use | Breakout USB port and BOOT pin, make it easy to debug without disassembling the enclosure. PWR indicator, RGB LED, and passive buzzer outside the enclosure | Comes with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
_ Onboard unibody power supply isolation, provides stable isolated voltage, needs no extra power supply for the isolated terminal
_ Onboard photocoupler isolation, prevent interference from external high-voltage circuit connected to the relay
_ High quality relay,
contact rating: 10A 250V AC or 10A 30V DC. ABS protection enclosure with rail-mount support, easy to install, safe to use
_ Breakout USB port and BOOT pin, make it easy to debug without disassembling the enclosure. PWR indicator, RGB LED, and passive buzzer outside the enclosure
_ Comes with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)
_ Onboard photocoupler isolation, prevent interference from external high-voltage circuit connected to the relay
_ High quality relay,
contact rating: 10A 250V AC or 10A 30V DC. ABS protection enclosure with rail-mount support, easy to install, safe to use
_ Breakout USB port and BOOT pin, make it easy to debug without disassembling the enclosure. PWR indicator, RGB LED, and passive buzzer outside the enclosure
_ Comes with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)
