Basics
Default: User: admin; Password: 12345; IP: 192.168.120;
Model: ZSD8WNH16A
Sensor: 1/2.8" SONY STARVIS Progressive Scan CMOS Sensor
Mode: IR ON when no human, Warm Light ON when human is detected
Lens: 2.7-13.5mm(5x Auto Focus Varifocal Lens)
WDR: 120dB
Electric Shutter: Adaptive, 1/2s-1/1,000s
Video & Audio Encoding
Video Encoding: H.265/H.264 Video Encoding
Audio Encoding: AAC/G.711U/G.711A Audio Encoding; Audio Sampling up to 32K
Bit Rate: CBR & VBR; 256kbps~8Mbps [Adjustable]
Frame Rate: 50Hz: 1-25fps; 60Hz: 1-30fps [Adjustable]
Main Sream: 3840*2160@15fps, 3072*2048, 2592*1944, 2592*1520, 2304*1296, 1920*1080, 1280*720
Sub Stream: 704*576, 640*360, 640*480, 352*288
RTSP(Main Stream): rtsp://192.168.1.120:554/Iive/0
RTSP(Sub Stream): rtsp://192.168.1.120:554/Iive/1
Protocol
Network Protocol: IPv4/IPv6, TCP/IP, DHCP, HTTP, UDP, RTP, PPPOE, SMTP, UPNP, VOIP
Video Protocol: CGI, RTSP, RTMP, ONVIF, HTTP, SIP, 802.1x
Interfaces
Network Interface: 1ch RJ45 10M/100M Self Adaptive Ethernet Port
Audio Interface: 3.5mm Audio Line-in Port
Wireless Protocol: Available by Default
Others
Working Environment: Temparature-30°C~60°C (-22°F~140°F); Humidity: 95% (Non-Condensing)
Power Input: Powered by Standard PoE Switch or DC12V 1A or Higher (Included by Default)
Power Consumption: 5W
Package Contents
1x 4K 8.0MP 5X Optical Zoom Dual Light Outdoor Bullet PoE IP Camera
1x Matched Power Adapter DC12 2A
1x Attached Accessories
NOTE
Audio might not be so good when streaming live video to YouTube.
