DVR Specification:
Video Format:H.264+
IP Video Input:16CH Wireless
Video Output:HDMI Up to 4K
Audio Output:Support
Max Recording Resolution:Up to 8M
Max Playback Resolution:Up to 8M
Max Playback Channel:4CH
Max Playback Capacity:4CH 5MP/2CH 8MP
HDD:1 SATA interface
HDD Capacity:Up to 8TB capacity(2.5&3.5 inches)
Network Interface:RJ45x1(10/100M)
Wireless antenna:3 Ports(2.4G&5.8G dual-bandIEEE802.11b/g/n/ac)
USB:USB2.0x2
Housing:Metal for mainpart
Operating Power:DC12V
Power Consumption:6 W (Without HDD)
Camera Specification:
Video Resolution:4MP(1920*
[email protected])
Image Sensor:1/3" Progressive Scan CMOS
Video Compression:H.264+
Video Bitrate:32Kbps~2Mbps
Audio Compression:G.711A
Lens:4mm
Angle of View:horizontal 75°, vertical 41°
Number of Infrared/Full color LEDs:4+4
Night Vision/Full color Distance:Up to 20m/10m
PT:Horizontal 350°, Vertical 90°
IR-Cut Filter:Yes
Ethernet:RJ45WIFI2.4G&5.8G dual-bandIEEE 802.11.ax
Housing:Plastic
Operating Power:DC12V
Storage:Micro SD Cardup to 256GB
Operating Temperature:-4 °F 122 °F /-20 °C 50 °C
Indoor/Outdoor:Indoor/Outdoor
Weatherproof Rating:IP66
Mount Option:Ceiling mount/Wall mount
