Package
Camera: 1pcs
Adaptor: 1xDC 5V 1A
Camera
Image Sensor: 1/2.9"CMOS sensor
Resolution: 2MP 1080P
Effective Pixels: 1920(H)*1080(V)
Compression: H.265
Electronic Shutter Time: Auto(1 / 12s~1 / 100000s)
S/N Ratio: 40dB
Scanning System: Progressive
Video Output: Wireless network
Reset Button: Yes
PTZ
Horizontal Rotation: Range 0~355°
Tilt Rotation Range: 0~60°
Lens Type
Focus Length: 3.6mm F2.0
Focus Control: Fixed
Lens Type: Fixed
Pixels: 2M Pixels
Night Vision
Infrared LED: 14µ x 4PCS
Infrared Distance: 5~10M
IR Status :CDS Auto Control
IR Power: On Auto Control
Network
Ethernet: RJ-45 (10/100Base-T)
Protocol: TCP/IP?UDP?HTTP?DDNS?DHCP?FTP?NTP
ONVIF /
P2P : Support
POE /
Main Stream 1 :1920*1080@25fps
Main Stream 2 /
Main Stream 3 /
Sub Stream 1: 640*360@25fps
Sub Stream 2 /
Sub Stream 3 /
Tri Stream /
IE Brower /
Smart Phone support
Wireless
Antenna: 3dbi
Hotspot: Support
Wi-Fi: Wi-Fi(IEEE802.11b/g/n)
WIFI Range :No obstacles 350m Max.
Camera Features
Day/Night: Color/ B&W (IR-CUT )
Minimun Illumination: 0.01 Lux
Image Config: YES
Corridor: Pattern /
ROI /
Defog Mode /
BLC /
HDR /
3DNR: Support
DWDR :Support
Motion Detection: Support
Privacy Masking /
Recording Mode: SDcard
Language: Chinese?English
Interface
Audio: 2-Way Audio
Alarm: Motion Detection
SD Card Slot: Support Max 128G
General
Housing: plastic
Bracket: Support
IR Cut Filter :YES
Operation Temperature:-10? ~ +50? RH75% Max
Storage Temperature :-20? ~ +60? RH75% Max
Size: 90(W)x155(H)x88(D)mm
