1080P HD AHD/CVI/TVI/CVBS 4X Optical Zoom PTZ Camera Night Vision NTSC System
- Note:The factory default mode is AHD. If you need TVI,CVI or CVBS mode, please let us know, thank you!
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
Note:The factory default mode is AHD. If you need TVI,CVI or CVBS mode, please let us know, thank you!
Specifications:
| Model No. | SP-AHD345-4X |
| Sensor | 1/3Progressive scan CMOS |
| Lens | 4x 2.8mm~12mm |
| Total pixel | 2.0MP |
| Resolution | HD:1080p/30fps /1080p/25fps |
| Rotation | Pan:355º Tilt:70º |
| Pan speed | 0-25°/s |
| Tilt speed | 0-20°/s |
| Auto Flip | Support |
| Ration speed | Support |
| IR range | 35M |
| IR control | PWM |
| AB scan | Support, 0-355 degree |
| AB speed | 1-9 grade selectable |
| Preset | 220 |
| Tour | 3 groups ( each group 16 presetdwell time and speed selectable) |
| Calibration | support |
| BW | Auto |
| Focus | Auto/Manual |
| BLC | Adjust |
| Video interface output | AHD/TVI/CVI/CVBS |
| Communication mode | RS485 (+/-) / coaxial cable |
| Power | DC12V(2A) |
| Temperature | -30~+60 |
| Consumption | 10W |
| Thunder Proof | 3000V |
| Size | Ø110X96mm |
| Weight | N.W 0.55kg/G.W 0.7kg |
