4000W 100A MPPT Solar PV Regulators 12V 24V 36V 48V Solar Charge Controller LCD

Features:
LCD Liquid Crystal Display: The solar charging controller adopts an LCD liquid crystal display with backlight display, which can be clearly and intuitively displayed in the dark, one-key operation of the panel keys can adjust various system control parameters, such as float charging voltage, boost charging voltage, light control and time delay, etc.
Multiple Operating Modes: This solar charge controller has seven operating modes, such as charging mode, light control mode, light and time delay control mode, universal control mode, manual control mode, timing control mode and testing mode, among them, test mode is only available to the factory test.
Large-section Wiring Port: Use large-section, large-spacing wiring ports, can be installed 16mm wire, the wire spacing of 7mm increases the insulation performance and the reliability of installation, effectively reduces current and voltage drop while reducing losses.
Dual USB Charging Ports: The solar charge controller adopts a dual USB charging port design, which can charge two devices at the same time, and supports most of USB port devices, such as mobile phones, tablets, PSP game consoles, etc.
Thickened Aluminum Alloy Heat Sink: The MOS tube is used to lock the heat sink design, the heat dissipation is more uniform, and there is no fear of the temperature rise caused by the MOS tube, the powerful heat dissipation capacity can operate normally in the environment of 55, at the same time, it is equipped with functions to prevent overcharge, overvoltage, DC output low voltage, high voltage protection and reverse polarity protection, etc.

Specifications

:
Name: Solar Controller
Material: plsctics+aluminum
Current: 100A
Input voltage: DC12V/24V, DC36V, DC48V
Output voltage: DC12V/24V, DC36V, DC48V, DC5V/ 1.5A *2USB
Working temperature: -25 to 55
Item size: 198 * 180mm / 7.80 * 7.09 in
Package size: 195 * 184 * 66mm / 7.68 * 7.24 * 2.60 in
Package weight:
100A: 1150g / 2.54 lb
Packing List:
1 * Solar Controller
1 * Guideline
