Audiocodes Mediapack MP114 4-Ports FXO VoIP Gateway MP114/4O/SIP/CER

Product Information

• Part Number: MP114/4O/SIP/CER
• Manufacturer: AudioCodes
• Product Line: MediaPack Series
• Product Model: MP114
• Product Name: Audiocodes Mediapack MP114 4-Ports FXO VoIP Gateway MP114/4O/SIP/CER
• Product Type: VoIP Gateway

Product Description

The AudioCodes MediaPack MP114/4O/SIP/CER is a compact and cost-effective analog VoIP gateway designed to connect legacy analog communication equipment, such as PBXs, key systems, or analog phones, to IP-based voice networks. Specifically, the '4O' in the part number indicates four FXO (Foreign Exchange Office) ports, meaning it connects to analog telephone lines (PSTN lines) or to FXS ports of a PBX. It supports SIP (Session Initiation Protocol) for signaling and is designed for carrier-grade reliability ('CER'). This gateway is ideal for small to medium-sized businesses and branch offices looking to leverage the benefits of VoIP while preserving their existing analog infrastructure.

Product Specifications

• Analog Ports: 4 x FXO (Foreign Exchange Office)
• VoIP Protocol: SIP (Session Initiation Protocol)
• Ethernet Ports: 2 x 10/100/1000Base-T Ethernet (RJ45)
• Voice Processing: Full duplex audio, Echo cancellation (G.168), Jitter buffer, Packet loss concealment, DTMF relay, CNG, VAD
• Voice Codecs: G.711, G.723.1, G.726, G.729AB, iLBC
• Signaling Protocols: SIP, MGCP (optional firmware)
• Fax Support: T.38 Fax Relay (compliant with ITU-T T.38 standard)
• Modem Support: Pass-through
• Power Supply: External AC/DC Adapter (Input: 100-240 VAC, 50-60 Hz)
• Management: Web-based management, Telnet, SNMP, AudioCodes Element Management System (EMS)
• LED Indicators: Power, Status, LAN Activity, FXO Port Status
• Mounting: Desktop or Wall-mountable
• Dimensions (WxDxH): 172 x 135 x 41 mm (6.8 x 5.3 x 1.6 inches)
• Weight: 0.4 kg (0.88 lbs)
• Operating Temperature: 0° to 40° C (32° to 104° F)
• Humidity: 10% to 90% non-condensing
• Compliance: CE, FCC Part 15 Class B, UL, TUV, RoHS, WEEE
