LSI 9300-8i PCI-Express 3.0 SATA / SAS 8-Port SAS3 12Gb/s HBA - Single--Avago Technologies

Add Internal 12Gbps SAS and 6Gbps SATA Connectivity to Rack-mount Servers and Workstations The LSI 9300-8i 12Gbps SAS Host Bus Adapter provides increased connectivity and maximum performance for high-end servers and appliances within internal storage, or connecting to large scale storage enclosures. The low-profile form factor, along with the included full-height bracket, allows for easy installation. KEY FEATURES Improved Connectivity The LSI 9300-8i is based on the SAS 3008 IO controller, integrating the latest enhancements in SAS and PCI Express technology. It supports eight PCI Express lanes that comply with the latest PCI Express 3.0 specifications.

The support for both SAS and SATA drives gives flexibility in designing storage architectures and helps protect existing infrastructure investments. Now, you can easily connect to up to 1024 SAS and SATA devices with its built-in eight internal 12Gbps SAS and SATA ports. High Performance The LSI 9300-8i provides up to 12Gbps SAS and up to 6Gbps SATA performance across eight lanes of PCIe 3.0 connectivity. In addition, its also backwards compatible with previous SAS and PCIe generations through automatic negotiation, and provides SAS data transfer rates of 6Gbps and 3Gbps per lane, and SATA data transfer rates of 3Gbps per lane.

Easy Installation The LSI 9300-8i fits into 1U/2U rack-mounted servers and workstations with a low-profile form factor (full-height bracket included. ) Learn more about the LSI 9300-8i Model Brand LSI Model 9300-8i Part LSI00344 Form Factor Low Profile Details Type SATA / SAS Internal Connectors 2 x SFF-8643 mini-SAS HD Interface PCI-Express 3.0 Transfer Rate Up to 12Gb/s Dimensions 6.00" x 2.60" Features Features Connect up to 1024 SAS and SATA devices with 8 internal 12Gb/s SAS and SATA ports Fit into 1U/2U rack-mounted servers and workstations with low-profile form factor (full-height bracket included) Provide up to 12Gb/s SAS and up to 6Gb/s SATA performance across 8 lanes of PCIe 3.0 connectivity Package Contents Package Contents 9300-8i HBA, Documentation CD *1 year warranty Packaging
Details Unit Type: piece
Package Weight: 0.5 kg ( 1.10 lb.
) Package Size: 30cm x 25cm x 10cm ( 11.81 in x 9.84 in x 3.94 in)
