HPE MSA 2060 16Gb Fibre Channel SFF Storage - 24 x HDD Supported - 0 x HDD Installed - 24 x SSD Supported - 0 x SSD Installed - Clustering Supported - 2 x Fibre Channel Controller - 24 x Total Bays -

HPE MSA 2060 16Gb Fibre Channel SFF Storage - 24 x HDD Supported - 0 x HDD Installed - 24 x SSD Supported - 0 x SSD Installed - Clustering Supported - 2 x Fibre Channel Controller - 24 x Total Bays - 24 x 2.5" Bay - 2U - Rack-mountable

Key Features | Accelerate Applications Affordably

The HPE MSA 2060 is capable of delivering up to 395,000 IOPS for affordable application acceleration for small to medium-sized businesses.

The HPE MSA 2060 allows users to define and deploy hybrid or flash storage configurations day one and grow as their needs change.

HPE MSAs Set It And Forget IT Data Services Does Not Require a Dedicated Storage Administrator

The HPE MSA 2060 Storage is easy to install, easy to use, easy to maintain, even for an IT generalist. Administrators will find the HPE MSA 2060s new Storage Management Utility intuitive and easy to navigate.

HPE MSAs automated tiering engine dynamically responds to workload changes so you dont have to, ensuring the hottest data will be moved to the fastest media automatically and in real-time.

Leverage Data Protection Features to Keep Your Business Running in the Event of a Disaster

The HPE MSA 2060 Storage delivers virtualized snapshot technology making data protection and instant recovery a snap.

Remote replication via Fibre Channel (FC) or iSCSI facilitates a affordable disaster recovery solution.

Encrypted SSDs and HDDs with local key management can be deployed to deliver a secure, encrypted hybrid flash array.

Flexible, Modular Architecture That Facilitates Growth Into the Future

The HPE MSA 2060 Storage solution supports a mixture of 3.5 inch LFF and 2.5 inch SFF expansion enclosures for a maximum of 9 enclosures (10 total including the array).

Start small and scale as needed with any combination of SSDs, Enterprise SAS or MidLine SAS HDDs.

Specifications:

Interfaces/Ports

• Host Interface Fibre Channel

Miscellaneous

• Energy Star Yes

Controllers

• Controller Type Fibre Channel
• Number of Controllers 2

I/O Expansions

• Number of Total Expansion Bays 24
• Number of 2.5" Bays 24

Storage

• Number of Hard Drives Supported 24
• Number of Hard Drives Installed 0
• Number of Solid State Drive Supported 24
• Number of Solid State Drive Installed 0
• Clustering Supported Yes

Physical Characteristics

• Weight (Approximate) 11.02 lb
• Form Factor Rack-mountable
• Rack Height 2U
• Height 3.5"
• Width 17.5"
• Depth 20"
