Capacity: 5.0A h (30WH)
Chemistry: Lithium Phosphate (LiFePO4)
LED indicator shows battery capacity status: Full, Mid or Low
Working Voltage: 12.8V
Peak Voltage: 15.2V
Cut off voltage: 9.6V
Charging Current: 2.5 Amp
Max Discharging Current: 10 Amp limited by PCB
PCB (10 Amp Limited) Protects pack from Overcharge (> 15.6V ), Over discharge ( <8.8V), Over Drain (> 40 Amp) and Short Circuits.
Cycle Life: >1000 (80% Capacity@ 0.2C rate, IEC standard)
Terminal: T1
UN 38.3 Passed
Length: 3.5" (90mm)
Width: 2.75" (70mm)
Height: 4" (101mm)
Weight: 1.5 lbs (700 gram)
Superior high temperature & storage performance make LiFePO4 the most suitable one for Li-ion battery positive material
Longer than 1000 cycle life is more suitable for application use.
Light weight and high energy density.
Installed IC chip will prevent the battery pack from over charge and over discharge. It helps protect battery chemistry integrity and prolongs battery life.
Highest Safety of all Lithium batteries
Ideal replacement for Lead Acid batteries. You get many more charges and Lighter weight.
